[00:00]
hello to this new tutorial today I want
[00:02]
to show you how you can interpolate big
[00:04]
piles of frames without running into
[00:07]
memory issues I got question in the
[00:09]
comments how to do this and I researched
[00:14]
it a little bit and I realized that
[00:17]
there is nothing like this workflow so
[00:20]
far so I created something which is
[00:25]
based on already generated images in a
[00:30]
folder and this workflow runs through
[00:33]
this folder step by step and generates
[00:36]
the interpolated frames between every
[00:39]
frame pair step by step without loading
[00:43]
the whole folder so that your rum is not
[00:47]
filled with all the frames and will not
[00:50]
overrun so only one interpolation is
[00:54]
done at once and this workflow goes
[00:57]
through your folder of images Step by
[01:00]
step this is based on a wild mix of
[01:04]
custom comy UI notes which I will list
[01:08]
in the description below it was quite a
[01:10]
wild ride to find the notes which work
[01:13]
well together but in the end everything
[01:15]
worked out so in the future I might make
[01:18]
a new version an updated version of this
[01:21]
workflow with more simple notes or maybe
[01:26]
a little bit easier to work with but for
[01:28]
now this is working it should help a lot
[01:31]
of you to work through big piles of
[01:34]
images and interpolate the whole bunch
[01:37]
of them through without having memory
[01:40]
issues let's start from scratch I want
[01:43]
to start with loading our images I use
[01:46]
the load image badge note from the V
[01:50]
note
[01:51]
suit so add note or suit
[01:56]
IO load image badge
[02:03]
I Define the path of all the frames I
[02:08]
want to interpolate
[02:10]
between and we use the single image mode
[02:15]
here we need to duplicate this since we
[02:19]
need two frames to interpolate between
[02:24]
and we need to pack our
[02:27]
frames to a batch
[02:34]
so we pipe both outputs into our batch
[02:39]
images node
[02:41]
to have a batch which we then can fill
[02:45]
into our interpolation
[02:48]
node I I use the
[02:53]
RVE interpolation note
[03:01]
I keep the settings uh like this for
[03:10]
now and then I want to save the
[03:14]
results for this I choose the V notepad
[03:23]
again and choose the image save note of
[03:27]
the V pack this note gives us a
[03:30]
possibility to define a folder where we
[03:34]
put our interpolated frames into we need
[03:39]
to Define which frame the load image
[03:43]
batch node will load in this case uh the
[03:47]
first note is uh has the index zero so
[03:52]
that means it's loading the
[03:55]
first
[03:57]
frame and this uh note needs the index
[04:01]
of one this means it's loading the
[04:04]
second
[04:06]
frame in
[04:08]
programming um you point up from zero
[04:13]
zero means one so in programming and
[04:20]
informatics uh you're starting at zero
[04:23]
just just at a side
[04:27]
note and this should give us results
[04:33]
already I will have a test so as a base
[04:36]
I take some simple animate diff uh
[04:40]
animation I did before and we see out of
[04:43]
those two frames there have been created
[04:46]
three frames if we push this up to 10 we
[04:50]
get 11 frames so this is only the first
[04:54]
step this is the basic interpolation
[04:56]
this only uses the first and the second
[04:59]
frame for now to go through our whole
[05:02]
pile of images we need to do some
[05:05]
Automation and special things now let's
[05:08]
first start by making an
[05:11]
automation to crank up our index we need
[05:15]
to count
[05:17]
up this value and this value one by one
[05:24]
so that we later can run through
[05:28]
everything sing frame frame for this I
[05:30]
use the incremental note out of the
[05:33]
musarat
[05:40]
noes this gives us the possibility every
[05:43]
time we run the patch the number in this
[05:47]
node will be increased and then we can
[05:49]
fill in this number to our load image
[05:53]
batch nodes we have to set this to
[05:56]
increment and now since we need
[06:01]
this note have the number one higher
[06:04]
than in this note so this the zero this
[06:08]
one when this is one I need this to be
[06:11]
two so we have
[06:13]
to add one to the output of this note to
[06:18]
fill the value into this note we could
[06:22]
take two of those
[06:23]
notes uh with the difference of
[06:26]
one to fill uh in the second
[06:31]
note but I find it easier like this way
[06:35]
so you only have to adjust one number in
[06:39]
the start of the workflow so this is
[06:43]
easier for the addition of one to this
[06:47]
number I use the number operation Noe
[06:51]
out of the V not
[06:58]
suit since this is taking numbers I have
[07:02]
to convert this
[07:05]
integer to a
[07:11]
number since this is not an input we
[07:14]
have to converted to an
[07:19]
input so right click on this arrow and
[07:23]
choose convert a to input now we can
[07:27]
fill in our integer
[07:30]
and it will be converted to a
[07:36]
number so we're filling this number a
[07:39]
into this number operation and we choose
[07:43]
addition as an action and now we need
[07:47]
another number which is added to number
[07:49]
a
[07:51]
so we use the into number again
[08:00]
put it to one and fill it inside our
[08:04]
number
[08:08]
operation and now we need
[08:11]
to convert the index settings of our
[08:17]
notes to inputs also right click on this
[08:21]
arrow and convert index to input and do
[08:26]
this for the first note for the first
[08:28]
batch note
[08:30]
also convert index to input and now we
[08:35]
can fill the integer value into our
[08:40]
index and we can fill this integer to
[08:45]
the first one so this seat is zero so in
[08:50]
the first PA of this workflow we have a
[08:53]
zero filled into the load image batch
[08:56]
node and it will load the first image
[08:59]
image out of the
[09:01]
folder for the second batch it it will
[09:05]
add
[09:06]
one this one to our zero so we get one
[09:10]
as an output and this gets number one as
[09:13]
an index and will load the second
[09:16]
image so sorry if this is a little bit
[09:20]
complicated uh with the zero and the one
[09:25]
and the shift of one number but uh it is
[09:28]
like it is in mathematics and in
[09:30]
informatics in programming like this and
[09:33]
I cannot change it but you will get
[09:36]
familiar with it if you're not used to
[09:38]
it this control after generate will
[09:41]
increment our number one step after each
[09:45]
generation and this will step through
[09:48]
our whole folder first time we use it
[09:51]
there will be index zero index one the
[09:54]
next time this will one so we will have
[09:57]
index one and index two this means the
[10:01]
second frame out of the folder and the
[10:04]
third frame will be loaded and
[10:06]
interpolated between then this will be
[10:08]
two that means the search frame will be
[10:12]
interpolated to the force frame and so
[10:16]
on so to automate this we need to use
[10:20]
the extra options in the Q prompt and we
[10:23]
need to check the auto que option so
[10:26]
after the after every gener Generation
[10:30]
The Prompt will be started again and the
[10:33]
number will be increased into one and it
[10:36]
will go through all your images step by
[10:39]
step and not all at once so they will
[10:42]
not be loaded everything into your rum
[10:44]
and this is much more RAM saving as if
[10:48]
you have to load everything to your room
[10:51]
but we're not finished yet we have one
[10:54]
problem this RVE Noe will output uh our
[10:57]
first frame and our second frame and all
[11:00]
the frames in between every time we run
[11:03]
this workflow that means that there will
[11:06]
be some frames doubled so when we
[11:09]
generate between first and second and
[11:12]
then between second and third the second
[11:14]
frame will be doubled and then when we
[11:17]
generate between third and fourth uh the
[11:20]
third frame will be doubled and the
[11:22]
fourth frame and the fifth frame and the
[11:24]
sixth frame and so forth this is because
[11:27]
the ri interpolation node
[11:29]
always all frames out so the first the
[11:33]
second and the frames in between and we
[11:35]
have a doubling of those end and first
[11:38]
frames every run now it gets a little
[11:41]
bit complicated we need some if and else
[11:45]
Logic for this we need to split our
[11:48]
image batch and separate the first frame
[11:52]
and only output the last frames with all
[11:56]
the starting frames because of the
[11:58]
duplication we need to make some space
[12:01]
here and run our batch of 11 images into
[12:05]
Split Image batch node it's part of the
[12:08]
VHS notes this can split our batch which
[12:12]
is consisting of 11 image in this case
[12:15]
and can output uh two batches and split
[12:18]
it at a certain point so in this case I
[12:20]
split it after index one this gives us
[12:23]
the first image of the batch to image a
[12:26]
and the 10 images after the go to image
[12:30]
B so let's have a image preview here and
[12:34]
an image preview here to see what we get
[12:39]
out of this note so let's
[12:42]
generate so what you see here is we get
[12:45]
our first frame here separated and then
[12:48]
the frames after that get outputed here
[12:51]
so this is 10 frames this is one and
[12:54]
this gives us all the 11 frames here
[12:57]
since the first generation generat the
[12:59]
images with the end frame we don't need
[13:03]
this end frame which is the same as the
[13:05]
starting frame for the Next Generation
[13:07]
we don't need the starting frame we can
[13:10]
split it off we only need those frames
[13:13]
since this would be double we have to
[13:15]
check if this worklow is running the
[13:17]
first time if so we put out every 11
[13:20]
frames if it is not we only put out
[13:24]
those 10 frames without the starting
[13:27]
frame to prevent the doubling we do this
[13:30]
with the image input switch note from
[13:35]
the v no
[13:44]
suit this um image input switch is quite
[13:49]
simple
[13:51]
depending of the Boolean input true or
[13:55]
false it's sending image a through to
[13:58]
the output or image B so we pipe our
[14:04]
splitted images into the image a port
[14:08]
and the unsplit images to the image B
[14:13]
port and now we need the Boolean
[14:16]
information true or false for this we
[14:20]
need
[14:21]
to make a logic uh operation and compare
[14:25]
our values so we use the comp Paran note
[14:29]
out of the comi logic
[14:37]
pack the bo part goes to the Boolean
[14:42]
input of this
[14:43]
note you already can connect the images
[14:47]
to the image safe
[14:49]
node and now we need some information
[14:53]
here so at first I connect
[14:57]
our n
[15:00]
index into the compare node to the a
[15:05]
input
[15:07]
and for the
[15:10]
bport I take another incremental
[15:17]
Noe so connect this to the bport and set
[15:22]
it to zero and set it to
[15:26]
fixed so we are comparing our initial
[15:32]
index which goes to a with the number we
[15:36]
put to be so the number is zero and we
[15:41]
look if a is bigger than b so if our
[15:47]
index is zero we
[15:50]
know it is not bigger than zero it is
[15:54]
equal so this is false so it gives false
[15:58]
to the image input
[16:00]
switch and this means our image B will
[16:04]
go through our
[16:06]
output if we process our workflow
[16:10]
another time the index will be
[16:13]
one and therefore it is bigger than our
[16:17]
zero so that means the compare node will
[16:20]
output
[16:22]
two and this gives the input switch the
[16:25]
information to to bypass the image a
[16:30]
output to the safe note that means the
[16:34]
reduced the splitted batch without the
[16:37]
starting image so that we don't have
[16:39]
duplicate
[16:41]
images and this will be done until our
[16:44]
batch is done so what is really
[16:47]
important for the incremental note at
[16:50]
the beginning is that this max value is
[16:53]
bigger than the amount of images you
[16:55]
want to process so if you have let's say
[16:59]
200 images this should be bigger than
[17:02]
200
[17:04]
so just put in a super big number and
[17:07]
you will be fine let's have another
[17:12]
look so let's put the multiplier a
[17:15]
little bit
[17:18]
smaller and let's put our seat again
[17:22]
back to
[17:25]
zero and
[17:30]
we should be good to go let's give it a
[17:33]
try let's disable the auto que again for
[17:37]
a test this should output our first
[17:39]
image the interpolated image in between
[17:42]
and the last image now if we run it for
[17:46]
the first time
[17:48]
so that should the output should be
[17:50]
three
[17:52]
images so there we are we have our three
[17:56]
images every other
[17:59]
generation should output two images only
[18:03]
depending on this
[18:06]
logic and so that we have no duplicate
[18:10]
images so let's do it another one it
[18:13]
should only output two
[18:16]
images there we go two images another
[18:19]
one should only output two images
[18:24]
again and there we go it's going through
[18:27]
our batch
[18:30]
step by step and calculating the images
[18:34]
between every pair of images so we can
[18:39]
hit the auto que feature again and let
[18:43]
it run
[18:44]
through so we're ending with this error
[18:47]
message there is no object left to
[18:49]
process this workflow can used for as
[18:52]
many images as you like so yeah let's
[18:55]
have a look at the results really smooth
[18:58]
because of the
[19:01]
interpolation and I cannot see any
[19:06]
double images since this uh workflow is
[19:09]
quite complicated I decided to put it on
[19:12]
my GitHub page so that you can download
[19:15]
it uh maybe a quick walk through how you
[19:20]
would use it it's important to set your
[19:23]
folder path
[19:27]
here on both
[19:29]
uh load image batch
[19:32]
notes should both be the same path then
[19:36]
you need to adjust the seat settings to
[19:44]
zero and
[19:46]
then set your output pass and then you
[19:50]
should be good to go I put a link to the
[19:53]
file on my GitHub in the description
[19:55]
below as well as links to all the custom
[20:00]
notes you need I hope this walk through
[20:04]
this tutorial helps you and please
[20:06]
subscribe and like the video I hope to
[20:09]
see you soon goodbye
