7 Simple Arduino Projects for Beginners

[00:00] In this video we will look at 7 simple projects

[00:07] Most of them will be based on Arduino Uno:

[00:12] enough input and output pins for most tasks.

[00:18] working on today can be implemented using

[00:24] the Arduino IDE automatically compiles your sketch

[00:30] I would say, is its huge advantage. As you

[00:38] We will also be using this cute project board

[00:44] it you may find in the description. It fits

[00:51] bread-board, which is a compact rig, that allows

[00:57] soldering iron. Bread-board's holes are

[01:04] also the board contains dedicated holes for ground

[01:10] comes quite handy when assembling circuits... The

[01:17] way: basically it's hard to mess anything up here,

[01:22] and watch your fingers when you do it. Also note

[01:28] long. I've come across boards that were

[01:35] not necessarily that happens to you, but just

[01:42] cable will also be used to power the extension

[01:48] To make sure everything's working, let us first

[01:54] The diode is wired to digital pin 7 and positive

[02:02] I used the +5v rail here for no particular reason,

[02:05] it was easier to wire, but it doesn't really

[02:11] and you can just as well use ground to power your

[02:19] The recommended output current for ATMEGA328

[02:28] digital pins in parallel and switching them

[02:34] You have to remember though, that max total

[02:42] The first project we are going to

[02:48] Such devices rely on the electrical conductivity

[02:54] We will use a piece of standard PCB to produce

[03:01] Then, using a resistor in series, we will

[03:08] Initially our sensor will output 5v. As it will be

[03:15] between the plates. Current will flow and the

[03:22] This, accordingly, will be reflected by

[03:28] and our program, once a certain threshold

[03:34] Before we proceed to writing the sketch, we

[03:41] Let's set up an experiment...

[03:49] And the resistance of water turns out

[03:55] triggered reliably, the resistor's value must

[04:03] Basically, the only purpose of this resistor

[04:10] when the sensor is dry. If you experience

[04:17] Note, that both pins of the beeper will be

[04:22] and we will not use a ground connection here. This

[04:29] in opposite phase to create a bridge circuit,

[04:35] Ok, here's what our sketch will look like.

[04:41] and speaker pins for output, and initialize them.

[04:47] to read the value of the A/D converter and sound

[04:55] alarm() function plays tones and takes frequency

[05:04] As the sensor is flooded,

[05:09] Because flooding is an emergency, the alarm

[05:20] And... the alarm goes off again, because

[05:27] The maximum value Arduino's A/D converter

[05:34] the higher the degree of flooding. If necessary,

[05:40] value of this constant... Also, if we position the

[05:47] we can come up with water level sensor: its

[05:54] Note however, that electrical conductivity

[05:59] readings, so this method of level

[06:06] Our next device is the single LED automatic

[06:14] In low light conditions the LED lights up, and

[06:22] Here you can see the schematic

[06:27] When I said “the single LED”, I literally meant

[06:34] the LED. That's right! We are going to use the

[06:43] a light sensor, because LEDs can also sense light.

[06:50] this project will be a bit more complicated than

[06:57] microcontrollers! The problem is, the LED cannot

[07:05] But! Because LEDs switch really quickly, what we

[07:13] read the illuminance value, and then, based

[07:20] Here's the sketch source code. The LED is wired

[07:28] But how are we going to power the LED

[07:33] Actually, all analog inputs of

[07:39] if you use the appropriate pinMode command.

[07:45] And there's something else. Arduino's A/D

[07:52] This becomes even more evident if you keep

[07:58] So, to make our program more stable, we need to

[08:05] its less than 100 ms, but unfortunately,

[08:11] Also, while debugging the device

[08:16] After switching from digital to analog mode,

[08:23] This is probably caused by some transient

[08:28] we do not have time to wait for the offset to

[08:35] called “shelf” that takes care of this error.

[08:41] was found by trial and error method... If you

[08:48] you will probably have to play with this

[08:53] Here's the source code of the program. At the

[08:58] logic zero and then switch it to analog mode. Then

[09:05] performs 10 consecutive reads at 10 ms intervals.

[09:12] ADC errors and bounce. When we're done with the

[09:20] If the value read is greater than 220, we

[09:29] If the LED was turned on, we set the shelf

[09:37] Then there's a 2 seconds delay,

[09:42] Let's check it out! Ok,

[09:54] if said that the flicker is unnoticable, I would

[10:01] not necessary to read the illuminance value so

[10:08] minutes will quite suffice. The Sun doesn't set

[10:15] In that case I don't think anyone

[10:19] To adjust this interval you need to

[10:27] Our next project is the touch sensor doorbell.

[10:34] regular metal paper clip as a finger sensor, which

[10:41] We will also need a 1M resistor that we

[10:47] This device relies on the effect of

[10:52] phase wire located somewhere in

[10:56] When you touch the paper clip, the MCU registers

[11:03] action -- sounds a bell in our case. It should

[11:09] interference and noise. To protect from them

[11:17] But we have a microcontroller here,

[11:22] For the device to work properly, we need it

[11:27] on your country) Hz sine. Any other signals,

[11:36] To implement this, I wrote a simple frequency

[11:43] usually done by counting the number of transitions

[11:48] In our case it will be 25 ms – I picked it based

[11:56] pulses counted lies in the range of 70 to 150 –

[12:03] good signal... For now let us output the result

[12:13] As we can see, the program is quite stable and

[12:19] If the touch is too short, it's ignored.

[12:23] Now let's try to playback some sound. Of

[12:29] to buzz a primitive melody through the speaker.

[12:35] like a real old-school door-bell. I was able to

[12:41] sample without trouble, here's what it sounds

[12:48] a built-in D/A converter and it appears there's

[12:56] But! I found a quite remarkable library. It's

[13:04] it can play back 8-bit PCM format samples

[13:12] You need to download the library – the link is

[13:18] files into the “libraries” folder of Arduino

[13:24] PCM.c file and change the sample rate from 8000 to

[13:34] The sample file I got off the net has format

[13:42] 11025 Hz 8 bit mono – note it's the only

[13:53] Conversion is necessary because Arduino's memory

[13:59] Naturally, lowering the bit-resolution and

[14:05] case its not important. Now that we're done with

[14:11] from the WAV file and extract the raw 8-bit audio.

[14:19] Unfortunately, the Arduino IDE can not

[14:25] So, we need to convert our binary dump into

[14:31] To do it, we are going to use

[14:39] Here's what our bell sample looks like now.

[14:42] Let's save it into a separate file

[14:49] To play back the sample all we need to do

[14:55] Its only two parameters are name

[15:01] Please note, that you must wire the speaker

[15:06] assignment may not be changed. This is due

[15:12] hard wired to this pin inside the MCU.

[15:25] Our next project is the electronic ruler

[15:31] as displacement sensor. It's not secret to anyone

[15:40] However, the type of current such motor

[15:45] because the windings are constantly switched

[15:52] is periodically broken at a frequency

[15:57] This is the feature that our device will rely on.

[16:04] We will also use a two-digit 7-segment

[16:11] like in our previous sketches, data will be read

[16:18] It would be nice to implement counting in both

[16:23] in a digital caliper, for example. We know,

[16:29] change of EMF polarity on motor's output.

[16:35] We can use a resistor divider and shift

[16:41] In this case motor's positive EMF will increase

[16:48] But we would like our circuit to stay as

[16:55] We will wire the motor between two analog

[17:02] ADC ins of Arduino can turn into digital outs.

[17:10] in to digital mode and set it to logic zero

[17:16] Then we just switch them. This will

[17:22] the ADC. I should also note that solutions like

[17:23] pins are switched into different modes and sensors

[17:23] switching must happen much faster than

[17:23] The main loop of the sketch is before us. The

[17:30] We switch the A1 input into digital mode and

[17:37] If the value is greater than 0, we increment the

[17:45] and A1 are switched: A0 is now zeroed and A1 is

[17:54] counter is decremented. While experimenting I

[18:02] signal amplitude, which also affects the readings.

[18:08] factor, found empirically. The accuracy of the

[18:16] Let's check it out...

[18:22] Good! If you have an old CD-ROM sitting somewhere

[18:29] The next circuit we are going to look at

[18:37] Using this device, you can switch

[18:42] The circuit relies on the TSOP 1736 IR receiver.

[18:47] This element is not your regular photo-diode

[18:55] quality square wave signal, with noise and bounce

[19:02] In our case the IR-receiver is wired to line A2

[19:09] sketch, but we can still use all analog pins as

[19:20] to work, it also needs to be powered. LEDs are

[19:24] Hypothetically, if you want to control a

[19:30] you can get away with a simple D-type flip flop

[19:37] be very unstable, because it will react

[19:43] Like when you wanna switch channels on your

[19:48] your device will also be triggered. It may even

[19:54] bulb emits light in the infrared spectrum.

[20:01] button-presses on a certain remote control,

[20:08] Fortunately, Arduino already carries a

[20:14] To compile this sketch you need to add the library

[20:21] all you have to do is initialize it in your

[20:27] procedure compare decoded keycodes to a list of

[20:34] sketch in debug mode, read the keycodes of this

[20:40] As we can see, now pressing buttons on the

[20:49] The last device we are going to build today is

[20:59] on Arduino's ability to emulate USB slave devices.

[21:07] mouse, touchscreen, webcam, microphone, etc. To

[21:16] your Arduino to your PC using the regular USB

[21:24] Arduino boards can emulate USB port. I will be

[21:31] contain 4 cursor keys and a fire button. This

[21:38] If you wish, you can add more buttons to the

[21:45] Here is the schematic of the device.

[21:49] so we will use the INPUT_PULLUP

[21:53] To emulate USB keyboard we will use a

[21:59] For the sketch to compile successfully you must

[22:08] To use the library all you have to do

[22:14] Then, as a keypress is detected on the gamepad,

[22:17] call the corresponding library routine to

[22:23] At first glance, the algorithm is plain simple.

[22:31] In reality, it's a bit more complicated.

[22:37] you often have to hold a button down or

[22:43] For example, for them to be running, you

[22:48] For them to jump to the left, you must press

[22:54] To implement this correctly, the process of

[23:00] button press and button release. The events

[23:07] Fortunately, the Keyboard library supports this.

[23:11] Now, how do we differentiate between a button

[23:19] an old programmer's trick that accomplishes it.

[23:25] to the number of keys. There are 5 keys on our

[23:32] At the beginning of the loop we read all button

[23:39] At the end of the loop we copy these

[23:45] So, at the beginning of a new loop iteration all

[23:51] while the M varialbles will have the pre-stored

[23:58] Now all we have to do is compare these two arrays.

[24:06] current state is PRESSED -- note that PRESSED

[24:13] we send it to the USB interface. If the previous

[24:19] it means the user released the button. Send that

[24:27] the same, it means no event had happened, and

[24:34] While debugging the program I also added

[24:39] It performs 50 consecutive reads of

[24:44] Based on that it decides whether the button

[24:50] to eliminate switching bounce and is called

[24:57] LED will flash, and then a delay of 100 ms will

[25:06] have keycodes to be sent to USB interface. Space

[25:15] Shall we check it out? Looks

[25:30] And... that would be it for today! If you like

[25:37] to this channel and sharing it on social media.

[25:44] a comment. And if you'd like to drop me some

[25:50] that you can find in the description
