How To Setup OBS Studio Like A PRO! - (Best Settings, Overlays, Audio & MORE)

[00:00] You just clicked on the only video that

[00:02] you are ever going to need to set up OBS

[00:04] Studio for live streaming and recording

[00:07] content. Because in this video, I'm

[00:09] going to walk you through the entire

[00:11] process from start all the way up to the

[00:13] finish line. And if you are someone that

[00:15] is brand new to utilizing OBS Studio,

[00:18] I'm here to tell you that it's going to

[00:19] be okay. Because I'm going to make this

[00:21] video as stress-free as possible. And so

[00:24] by the end of today's tutorial, your OBS

[00:27] Studio will be ready to stream, record,

[00:29] and clip content both in horizontal and

[00:32] vertical. You will be able to stream and

[00:34] multi-stream to all of your favorite

[00:35] platforms such as Kick, Twitch, YouTube,

[00:39] Facebook, and yes, even including

[00:42] TikTok. I am also going to provide you

[00:44] with a multi-chat widget for you to read

[00:46] all of your chats all in one place. I'm

[00:49] also going to show you how you're able

[00:50] to split all of your audio sources so

[00:52] that we have complete control over your

[00:54] audio. And I'm also going to provide you

[00:56] with the best recording and streaming

[00:58] settings while also helping you set up

[01:00] your scenes, your sources, as well as

[01:02] your overlays. And so if that sounds

[01:03] good to you, let's go ahead and let's

[01:06] get started.

[01:09] And so going straight into the video,

[01:10] the very first thing you want to do is

[01:12] download OBS Studio. So we need to head

[01:14] on over to obsproject.com

[01:17] and all of the links I'm going to be

[01:18] utilizing in today's video is going to

[01:20] be in the description down below so that

[01:22] way you guys can go ahead and follow

[01:24] along. Now as you can see, it is

[01:26] available for both Windows, Mac, [music]

[01:28] and you also do have the option for

[01:30] Linux, but today we're just going to be

[01:32] focusing on both Windows and Mac. So go

[01:34] ahead and select the operating system

[01:37] that you are currently utilizing to

[01:38] download the installation. And then once

[01:40] you download OBS Studio, you'll be met

[01:42] with this particular screen right here,

[01:44] which is going to be your

[01:45] auto-configuration wizard. Now what I

[01:48] recommend you do is to select the very

[01:51] first option, which is optimized for

[01:52] streaming, recording in secondary. You

[01:55] are then going to select next and you're

[01:57] going to make sure that your base canvas

[01:59] resolution is set to 1920 by 1080.

[02:03] And then you want to make sure your FPS

[02:05] is set to either 60 or 30, but prefer 60

[02:09] when possible. This means it's always

[02:11] going to prioritize 60 frames per second

[02:13] unless your stream cannot handle it.

[02:15] Then you'll have the option to drop it

[02:16] down to 30 FPS. So we're going to go

[02:19] ahead and select next.

[02:21] And then for your service, you want to

[02:23] make sure that you have Twitch selected

[02:25] because inside of your settings there's

[02:27] going to be an option for Twitch bot

[02:29] track that we're going to select and

[02:31] that only is available if Twitch is your

[02:33] main built-in service.

[02:35] So we're going to make sure Twitch is

[02:37] selected and then we want to go ahead

[02:40] and connect our account instead of

[02:42] utilizing the stream key. The reason why

[02:44] we want to do the account is because

[02:46] it's going to provide us with a chat

[02:48] that we're going to be able to put on

[02:49] the side of our OBS screen as well as

[02:52] the ability to change our title for

[02:55] Twitch. So you want to make sure you

[02:57] utilize this option here.

[02:59] And then go ahead and just connect your

[03:01] account. And then once that's done, make

[03:02] sure both of these options are checked

[03:04] and then go ahead and select next. It's

[03:06] going to then do a bandwidth test based

[03:09] on your internet, but we're also going

[03:10] to do that again a little bit later

[03:12] because these settings we're actually

[03:14] going to customize it to give you the

[03:16] best possible performance. But let this

[03:19] go ahead and just run its test really

[03:20] quickly. And then once that's done, it

[03:23] should provide you with your final

[03:24] results and you can go ahead and select

[03:26] apply settings. And so now you should

[03:28] see that your chat for Twitch has

[03:31] populated right here. We can go ahead

[03:33] and just move this over to the side. So

[03:34] this is what I like to do. I like to

[03:36] have my chat right here on the

[03:37] right-hand side of my screen.

[03:40] And then for my stream title, I'm

[03:42] actually going to put that down here

[03:46] on this particular side.

[03:48] Let's see if we can get it to move. And

[03:50] so now you should have something that

[03:51] looks somewhat similar to this.

[03:54] And so, what I highly recommend doing if

[03:57] you want a little bit more

[03:58] customizability

[04:00] to your OBS Studio, I recommend coming

[04:03] over to docs. I recommend checking this

[04:05] option right here for full height docs.

[04:08] And this is going to give OBS the

[04:09] ability to take your dockable panel,

[04:11] such as your Twitch chat, your scenes,

[04:13] your sources, or custom browser docs,

[04:16] and it's going to have it expand to the

[04:18] entire vertical height of your OBS

[04:20] application. And so, I'm going to go

[04:22] ahead and edit this a little bit to get

[04:24] it how I want it.

[04:28] And this is ultimately what it should

[04:30] look like. Now, if your OBS does not

[04:33] have the same kind of color pattern as

[04:35] mine has, and you want to be able to

[04:37] customize it to fit your own personal

[04:38] aesthetic, you can always come down here

[04:40] to settings.

[04:42] You can go over to appearance.

[04:44] And then, this is where you can change

[04:46] the different color for your OBS. So,

[04:48] mine is acri.

[04:50] Uh, but if you click the drop-down menu,

[04:52] it provides you with different options

[04:54] that you can choose from. So, just

[04:55] select the one that you want, so that

[04:57] way it can look somewhat similar to

[04:59] mine. And then, select apply and okay.

[05:03] And so, once that's done, we now need to

[05:05] go ahead and we need to add in our

[05:06] vertical canvas, as well as our

[05:09] multi-stream widget. And so, in order

[05:11] for us to do that, we need to head on

[05:13] over to this website, atom.tv.

[05:17] Now, the plugins that I'm going to have

[05:18] us downloaded are free. So, you just got

[05:21] to scroll down a little bit.

[05:23] And then, you'll see right here,

[05:25] vertical free download, multi-stream

[05:29] free download. So, both of these are

[05:31] free. You're not paying a dime for any

[05:33] of these. I want you to go ahead and

[05:35] download both of these plugins. So, you

[05:38] just got to click on it one time.

[05:40] It's automatically going to start the

[05:42] download for you, as you can see right

[05:44] here. And then, we're going to go ahead

[05:46] and just click on the installation and

[05:48] then we're going to go ahead and just

[05:49] fully install this onto our computer.

[05:51] And then we're going to go back and

[05:52] we're going to do the same thing for the

[05:53] multi stream. So what you're going to

[05:54] want to do from here is you want to

[05:56] reset OBS. So we're going to go ahead

[05:58] and close it out and we're going to go

[05:59] ahead and open it back up. And so now

[06:01] you should have your vertical and your

[06:04] multi stream plugin listed. Uh so

[06:07] basically it can be somewhere down here.

[06:09] It can be like anywhere on your screen.

[06:10] Just look for a little tab that

[06:12] potentially says vertical.

[06:15] And then you will also have something

[06:16] that says vertical scenes as well as

[06:19] vertical sources. So mine is right over

[06:21] here. But it can be anywhere on your

[06:23] screen. So just look for wherever it

[06:25] says vertical.

[06:27] And so once you have it, you're going to

[06:29] come over here.

[06:30] And we're just going to just put it

[06:32] right on the side right here.

[06:36] Now if you don't see it at all, if you

[06:38] don't have it anywhere on your screen,

[06:40] what you can do is come over to your

[06:42] docks.

[06:43] And then you'll have all of these down

[06:46] here. It says vertical scene, vertical

[06:48] sources. We don't need the vertical

[06:50] scene transitions, but if that's

[06:52] something that you want to have, then

[06:53] you can go ahead and do that.

[06:56] I'm personally not going to do that.

[06:58] And then we're also going to add in our

[07:01] Atom multi stream. So this is our multi

[07:04] stream widget that's going to allow us

[07:05] to be able to stream to any platform of

[07:08] our choosing. So we're going to go ahead

[07:10] and just add this right over here. We're

[07:13] going to take our vertical scenes. We're

[07:16] going to put this on top of our regular

[07:18] scene.

[07:20] And then we're going to do the same

[07:21] thing for our sources. We're going to

[07:22] take our sources. We're going to put it

[07:24] over the regular source. So that way

[07:25] it's in this tab-like format. So all we

[07:28] got to do is just click on it and we can

[07:28] just go through them. Now I am going to

[07:29] go ahead and just rearrange this. I'm

[07:30] going to take the controls. I'm going to

[07:31] put this up under our chat and just

[07:34] bring this over a little bit.

[07:38] And then we're going to take our scene

[07:39] transitions and we're just going to put

[07:40] this inside of our audio mixer just so

[07:43] that way we still have it is just down

[07:46] here. And so now what we want to do is

[07:48] set up our scenes and our sources. Now

[07:51] there are five mandatory scenes that

[07:54] everybody should have. A starting soon

[07:56] scene, a just chatting scene, a gameplay

[07:59] scene, a [music] be right back scene as

[08:02] well as a ending soon scene. So we're

[08:05] going to go ahead and go over to our

[08:07] scenes.

[08:08] We want to go ahead and click on the

[08:09] plus icon.

[08:12] Uh we're going to go ahead and name this

[08:14] starting soon. We're going to go ahead

[08:16] and remove the first one.

[08:18] And then we're going to go ahead and

[08:19] just make the rest of them right here.

[08:29] And so once all of our scenes have

[08:30] [music] been created, we're going to

[08:32] come back to the starting soon screen at

[08:34] the top and then we're going to go ahead

[08:35] and add in our overlays for our sources.

[08:38] So the type of overlays that goes here

[08:40] is going to be like a chatting overlay

[08:43] in case you want your chat to appear on

[08:45] your screen inside of OBS for your

[08:48] viewers to see.

[08:50] And then you can have your starting soon

[08:52] animation [music]

[08:53] or static image. Now there's a bunch of

[08:56] websites that you can go to to get

[08:58] overlays, but if you're someone that

[09:00] does not have the money to buy an

[09:01] overlay if you don't have one, then what

[09:04] we're going to do for the sake of this

[09:05] tutorial is go over to this website

[09:08] hexium.net. And this website provides

[09:11] you with a couple of free overlays that

[09:13] you are able to download. If you just

[09:15] come over to the search bar,

[09:18] you type in the word free, you scroll

[09:20] down,

[09:21] and you select the option that says free

[09:23] designs. You will then be brought to a

[09:26] page where it has all of their free

[09:28] overlays that you are able to download.

[09:30] So for the sake of this video, I'm going

[09:32] to go ahead and click on this one right

[09:34] here which looks like it's incision and

[09:36] we're going to go ahead and we're just

[09:37] going to proceed to check out. You are

[09:39] going to have to put in your information

[09:40] here, but honestly, if you're not

[09:42] comfortable putting your information,

[09:44] you can always just put in like a fake

[09:45] name and a fake email address. And once

[09:47] that's done, you're now able to go ahead

[09:49] and select this download button. We are

[09:50] then going to go ahead and unzip the

[09:52] file, and so we can now go back into OBS

[09:55] Studio here.

[09:56] We're going to go over to our sources.

[09:59] We're going to click the plus icon, and

[10:01] if you're someone that downloaded an

[10:02] animated overlay, you're going to select

[10:04] media. However, if your overlay is a

[10:07] static image, which means that it does

[10:09] not move, then you're going to select

[10:11] image.

[10:12] But since mine is animated, I'm going to

[10:14] go ahead and do media.

[10:16] I'm going to name this starting

[10:19] soon overlay.

[10:21] I'm going to select okay.

[10:24] We're then going to select browse for

[10:26] local file.

[10:28] We're going to look for

[10:31] the overlay pack that we've downloaded.

[10:35] We're going to select animated.

[10:37] And then it should have everything right

[10:39] here for you. So, mine is starting soon.

[10:42] I'm going to select open.

[10:45] I'm then going to make sure I select

[10:46] loop,

[10:47] and then click okay.

[10:49] And it's now officially right here on my

[10:51] screen. And so, we're going to do the

[10:53] same thing for the be right back scene,

[10:55] as well as our ending soon scene.

[11:06] All right, perfect. So, we now have our

[11:08] starting soon, our be right back, and

[11:10] then our ending soon. Now,

[11:13] for this, if you are somebody that wants

[11:15] to have a chat up here on your screen,

[11:20] then what you're going to want to do is

[11:21] head on over to this website,

[11:22] lumiastream.com.

[11:24] Now, normally I would have recommended a

[11:26] Stream Elements, however, we got some

[11:28] unfortunate news that Stream Elements

[11:30] just might be shutting down due to

[11:32] financial reasons. And so, because of

[11:34] this, Lumia Stream is going to be the

[11:36] best alternative when it comes to

[11:38] setting up your widgets as well as your

[11:40] overlays. The only thing about Lumia

[11:43] Stream is that you are going to have to

[11:45] download this onto your computer. But, I

[11:48] promise you this is safe. I would not

[11:50] recommend anything that I would not put

[11:53] on my own computer. And so, once you're

[11:55] on this website, go ahead and download

[11:57] the application, which is available for

[11:59] both Windows and Mac.

[12:01] Now, once you download the application,

[12:03] you'll be met with this particular

[12:04] screen right here. You want to then go

[12:06] ahead and log in with your Twitch

[12:09] account. Once you go ahead and authorize

[12:11] it, you will then be met with some

[12:13] screens. You can go ahead and close

[12:14] these out, and then it's going to

[12:16] provide you with a couple options for

[12:18] you to sign in to all of your streaming

[12:20] platforms. So, that's going to be

[12:22] YouTube Twitch Kick Facebook TikTok.

[12:26] You can log in to all of those

[12:27] platforms. Once you do that, you'll be

[12:30] met with your dashboard right here. And

[12:32] if you did not get the option to log in

[12:34] to your streaming platforms, then what

[12:36] you can do if you're on this dashboard,

[12:38] you can scroll down to the very bottom.

[12:41] You'll see option that says connections.

[12:44] You'll click on it, and then it'll

[12:45] provide you with the options to log in

[12:47] to all of your accounts by selecting the

[12:49] option that says add new connection. And

[12:51] you will see it provides you with a list

[12:54] of platforms that you can go ahead and

[12:55] log in to right here. So, we're just

[12:57] going to focus on TikTok, Kick,

[13:00] Facebook, YouTube, and Twitch. Now, once

[13:04] that's done, we're going to go ahead and

[13:05] add in our chat overlay. So, I'm going

[13:07] to make this real simple for you. What

[13:10] you're going to do is you're going to

[13:11] come on the left-hand side.

[13:13] You're going to scroll down until you

[13:14] see the option that says core.

[13:16] You're going to select the option that

[13:18] says overlays. You are then going to

[13:20] select the option that says add new

[13:22] overlay.

[13:24] You are going to name this chat overlay.

[13:29] Add new overlay.

[13:30] And then you're going to get this screen

[13:32] pop up right here. We're going to select

[13:34] the option that says add layer.

[13:37] We're going to come down here to where

[13:38] it says streaming tools.

[13:41] And we're going to select the option

[13:43] that says chat box.

[13:45] This is literally all you have to do.

[13:48] All of your streaming platforms have

[13:50] already been added and integrated. So,

[13:52] for example, if I were to go over to my

[13:55] Kick account and I start typing in my

[13:57] chat,

[13:59] you're going to see it pop up green

[14:01] right here. And then if I were to go

[14:03] over to my Twitch

[14:05] and I were to start typing in my Twitch

[14:07] chat,

[14:09] you will see that it shows up as my

[14:11] Twitch color.

[14:13] Now, what you can do to make it a little

[14:15] bit easier for you is you can come over

[14:17] here to chat box settings.

[14:20] Select the option that says manage chat

[14:22] box.

[14:24] And then you will see here

[14:26] that it provides you with all the

[14:28] platforms that will be listed inside of

[14:31] your chat here. So, Twitch, YouTube,

[14:34] Facebook, TikTok, and Kick.

[14:36] We're going to select the option that

[14:37] says change theme.

[14:39] It provides you with five themes that

[14:42] you're able to use for your overlay. The

[14:45] ones that I personally like is going to

[14:47] be the Lumia glass theme and the Lumia

[14:49] bubble theme.

[14:52] I'm going to go ahead and choose the

[14:53] glass theme.

[14:55] I'm going to go ahead and click save.

[14:59] And then we're just going to

[15:01] adjust this a little bit.

[15:03] Then we can scroll down on the right

[15:04] hand side.

[15:06] We can go over to styling. And then we

[15:08] can just make this a little bit bigger.

[15:11] So, we can go to like 20.

[15:13] Now, if we scroll back up, the one thing

[15:14] that I like about Lumia is the fact that

[15:17] we have an option for a horizontal

[15:18] layout. So, if you don't want your chat

[15:21] going up and down like this, you can go

[15:23] horizontal from side to side.

[15:26] And then if you want it, you can also be

[15:28] in reverse. You can also hide the icons

[15:31] for the website. So for example, like

[15:34] how right now it shows the Twitch badge

[15:36] to let you know that this message is

[15:38] coming from Twitch, you can hide these

[15:40] badges.

[15:41] So that way you can put this on your

[15:43] screen and Twitch will have a harder

[15:46] time trying to figure out exactly where

[15:49] the chats are coming from in case if you

[15:51] run into any issues about multi-chat on

[15:54] your screen. Now once you have your

[15:56] overlay here, you can go ahead and

[15:58] select save.

[16:01] You can copy the URL.

[16:03] And then you can head back into OBS

[16:04] Studio.

[16:06] You are then going to go over to your

[16:07] sources.

[16:09] You're going to click on the plus icon.

[16:11] You're going to go up to browser.

[16:13] You're going to name this chat overlay.

[16:17] Select okay.

[16:19] You are then going to paste the URL in

[16:21] the URL section here.

[16:23] And then press okay.

[16:25] You can put this wherever you want.

[16:28] And then if you start typing,

[16:30] you will see that your chat now appears

[16:33] right here on your screen.

[16:36] And so you can make this a little bit

[16:37] bigger if you choose to. And that's it.

[16:40] Now we're going to head on over to our

[16:41] just chatting scene.

[16:42] And this is where we want to add in our

[16:44] webcam. So we're going to come over to

[16:46] our sources.

[16:48] We're going to click on the plus icon.

[16:50] And we're going to select the option

[16:51] that says video capture device.

[16:54] We are then going to name this webcam.

[16:57] We're going to select okay.

[16:59] You then want to go ahead and scroll

[17:01] down here.

[17:03] You want to change your resolution type

[17:05] to custom.

[17:07] You want to set your resolution to the

[17:08] highest resolution possible.

[17:12] And you then want to scroll down, make

[17:14] sure your FPS is at highest FPS,

[17:17] and then select okay.

[17:20] Now go ahead and make sure that your

[17:22] camera is at the full size of your

[17:25] screen. You can do that once again by

[17:27] right clicking,

[17:29] go over to transform, and just fit to

[17:32] screen.

[17:33] And so now if I plug in my webcam, we

[17:35] should now be able to see it officially

[17:37] show on my screen. All right, so I am

[17:40] now officially on my screen here. And so

[17:43] since this is a just chatting scene,

[17:45] we're going to keep this minimalistic.

[17:48] Um the only thing we really need is our

[17:49] webcam on here, but if you do have some

[17:52] overlays, then you are more than welcome

[17:54] to go ahead and put that here. Just

[17:56] follow the same process as before. Once

[17:58] again, if it's a static image, you'll

[18:00] just come over to your sources, and

[18:03] you'll just put in an image. But if it's

[18:05] an animated overlay, then of course you

[18:07] can do media, and then just make sure

[18:09] that you loop it, and you're good

[18:11] [music] to go.

[18:12] Now what you can also do here, um if you

[18:15] want to add chat, since that's what most

[18:17] people put on their just chatting scene,

[18:19] then you'll come over to your sources,

[18:21] you're going to go to browser, and then

[18:23] since we've already added our chat

[18:25] overlay on our starting soon screen, we

[18:27] can go ahead and click add existing,

[18:30] click chat overlay, and then press okay.

[18:34] And look at that, it's already right

[18:35] here on screen. You can put this

[18:37] wherever you like. Personally, I put

[18:40] mine right here on the right hand corner

[18:42] since it's kind of like a blank area.

[18:44] And then that's it, you're pretty much

[18:46] good to go at this point. So if we start

[18:48] typing,

[18:50] the chat

[18:51] continues flowing,

[18:53] and we can now go ahead and work on our

[18:56] gameplay scene. So let's go ahead and

[18:58] let's click gameplay here. And so

[19:01] there's a few ways on how you're able to

[19:02] add your gameplay onto your screen. So

[19:06] if you are on Windows, what you're going

[19:08] to want to do is click on the plus icon

[19:10] under your sources. You're going to see

[19:12] options known as display capture, game

[19:15] capture, and window capture. If you

[19:18] decide to do display capture, you are

[19:20] going to then select a specific display

[19:23] such as your monitor screen. So, for

[19:26] this, I would just go ahead and select

[19:28] my primary monitor. You will see that it

[19:31] appears directly on my screen, and then

[19:34] you can resize this to fit your

[19:36] particular screen if it's not fit

[19:39] correctly. Now, I have a ultra-wide

[19:42] monitor, so that's the reason why you

[19:43] guys are going to see black bars down

[19:44] here. However, just know that if you

[19:46] decide to use this option, it's going to

[19:49] show everything that appears onto your

[19:53] screen. And so, if you don't want that,

[19:55] then you have a second option, which is

[19:56] going to be the game capture, and then

[19:59] you'll be able to capture any

[20:00] full-screen application. So, as long as

[20:02] your game is in full-screen mode, it's

[20:05] automatically going to show up right

[20:06] here inside of OBS Studio. So, you can

[20:08] go ahead and select okay,

[20:10] and you now have game capture. And this

[20:14] is not going to show anything else that

[20:16] comes up on your screen.

[20:18] And the third way is going to be your

[20:20] window capture. And so, we can go over

[20:22] to the sources, click on the plus icon

[20:24] once more,

[20:25] window capture,

[20:27] and then if we were to go ahead and

[20:29] select this here, this is basically

[20:31] going to ask us to select a specific

[20:33] window, and you will now officially be

[20:35] able to see that Marvel Rivals is

[20:37] appearing on my screen. Now, really

[20:39] quickly, if you're going to be utilizing

[20:40] the window capture, I highly recommend

[20:43] changing your capture method from

[20:45] automatic because at least for me, it

[20:48] automatically freezes up on my screen.

[20:51] So, click on the drop-down menu, and

[20:53] then select Windows 10, and it should

[20:55] automatically fix itself.

[20:58] And so, go ahead and select okay, and

[21:00] you now officially have three ways on

[21:02] how you're able to add your gameplay on

[21:05] your screen. So, choose whichever one

[21:07] works best for you, and then we'll go

[21:09] ahead and move on to the next step. Now,

[21:11] if you're somebody that is on Mac, the

[21:13] process for you is just a little bit

[21:15] different, but everything else is still

[21:17] the same. So, for you, what you're going

[21:19] to do is head on over to your sources.

[21:22] You're going to click on the plus icon,

[21:25] and then you're going to see an option

[21:26] that says Mac OS screen capture.

[21:30] You're going to select that. You can

[21:31] title this whatever you like, and then

[21:34] for the method, you'll have a drop-down

[21:36] menu with the three options, just like

[21:39] Windows. So, it's going to be display

[21:41] capture, window capture, and application

[21:43] capture. The application capture is the

[21:46] same as the game capture on Windows, as

[21:49] well as the display and window capture.

[21:52] So, for example, if you were to select

[21:54] the application capture, you're going to

[21:56] then select your display,

[21:58] and you are then going to select the

[22:00] application that you want to stream.

[22:03] So, if you have your game up, you go

[22:05] ahead and select it, and you will see it

[22:07] now show up inside of your preview. Once

[22:09] that's done, go ahead and select okay.

[22:11] Now, go ahead and resize it to fit the

[22:13] screen, and you're good to go.

[22:15] Now, if you want to go ahead and add in

[22:16] your webcam for this scene, just like

[22:18] how we did for just chatting, so that

[22:20] way your viewers can see you, then we're

[22:22] going to go through our sources. We're

[22:24] going to click the plus icon,

[22:26] video capture device, and then you will

[22:28] see that our webcam is still listed. So,

[22:31] we're going to select the option that

[22:32] says add existing, select the webcam,

[22:35] and then press okay.

[22:37] You can then go ahead and just resize

[22:39] this,

[22:43] and then you can just put yourself on

[22:44] your screen right here.

[22:47] And so, that's it. So, if you want to

[22:49] also add in your chat overlay, so that

[22:51] way it appears on your OBS screen, so

[22:55] that way your viewers can also see the

[22:56] chat, then what you can do is click on

[22:59] the plus icon,

[23:00] go back over to browser. You'll see that

[23:02] we still have our chat overlay sitting

[23:04] right here. So, we'll click add existing

[23:06] once more.

[23:07] Click on it. Press okay.

[23:09] The chat shows right here.

[23:12] And then we can just

[23:14] put this anywhere that we choose. I'm

[23:17] going to go ahead and just leave it

[23:18] right here.

[23:19] And you're now good to go.

[23:21] And so now what we're going to do is add

[23:23] in the rest of our platforms that we're

[23:24] going to be streaming to. So, if you are

[23:27] someone that's going to be streaming to

[23:28] Kick, YouTube, Facebook, or even TikTok,

[23:32] this is going to be for you. So, to add

[23:34] the rest of your platforms, we need to

[23:35] go over to the Aitum multistream doc.

[23:38] We need to click on the gears icon.

[23:41] It's going to bring up our main canvas,

[23:43] which is our horizontal canvas.

[23:46] And it's also going to bring in a tab

[23:47] for your vertical canvas, which is the

[23:49] vertical canvas right here.

[23:51] We are going to select the main canvas.

[23:54] We're going to select add output.

[23:56] And then you will see that it provides

[23:58] you with all the services that we are

[24:00] able to utilize. So, we got YouTube,

[24:02] TikTok, Facebook, Kick. And if there's

[24:04] anywhere else you want to stream to, you

[24:06] can also do a custom destination, which

[24:08] is right here. Let's go ahead and let's

[24:10] do YouTube for now. So, we're going to

[24:11] click on it. It's automatically going to

[24:13] provide us with our YouTube server. So,

[24:15] the only thing we got to do is come down

[24:17] here to YouTube stream key.

[24:19] We're going to click on this link right

[24:20] here. It's going to take us directly to

[24:23] our YouTube dashboard if you are already

[24:25] signed in to your YouTube account.

[24:28] Once you are on this page,

[24:30] the only thing you need to do is just

[24:32] press on the copy button

[24:34] to get your stream key.

[24:37] You're going to go back into OBS Studio,

[24:39] and you're just going to paste it right

[24:41] here. You're then going to select create

[24:43] output.

[24:44] And you have now successfully added

[24:46] YouTube.

[24:47] So, we're going to do the same thing for

[24:48] Kick and Facebook.

[24:54] Now, for Facebook, it is a little

[24:56] different. Uh on here, what you're going

[24:58] to do is click right here inside this

[25:00] box to set up your live video. Once the

[25:03] page load, you are going to select the

[25:05] option that says streaming software, and

[25:07] then you will have your stream key

[25:09] listed right here. Just go ahead and

[25:11] click copy,

[25:12] and then you can paste it inside of OBS

[25:14] Studio.

[25:16] Now, as a reminder, you do not have to

[25:18] do Twitch because Twitch is

[25:19] automatically built inside of Aitum

[25:22] Multistream already because we have

[25:24] already added our Twitch account inside

[25:27] of OBS Studio. So, there's no need to

[25:28] add it cuz it's already there.

[25:31] So, once that's done, we can select

[25:33] okay. You will see now that we have the

[25:35] platforms that we can stream to. And so,

[25:37] to now set up our vertical canvas so

[25:39] that we can stream to YouTube Shorts,

[25:41] what we're going to do is click on the

[25:43] gear icon once more.

[25:46] We're now going to go over to vertical

[25:47] canvas,

[25:48] and we're just going to add YouTube once

[25:51] again.

[25:52] So, click on this link again to go ahead

[25:53] and bring up your YouTube dashboard. And

[25:56] then, what we're going to do here this

[25:57] time is we're going to add in a

[25:59] different stream key. So, you're going

[26:01] to come up to the top. You're going to

[26:03] click on this drop-down menu right here

[26:05] that says default stream.

[26:07] And then, you what we're going to do is

[26:08] create a new stream key.

[26:12] We're going to name this vertical,

[26:14] and then we're just going to click on

[26:15] okay. So, now we have a vertical stream

[26:17] key, and then we have our default stream

[26:19] key. So, we're going to go ahead and

[26:21] copy our vertical.

[26:24] We're going to go back to OBS Studio,

[26:26] and we're going to paste that stream key

[26:27] right here.

[26:29] We're going to now create the output,

[26:31] and you're now good to go. So, we're

[26:32] going to go ahead and select okay.

[26:34] And so, now we have a vertical canvas as

[26:37] well as our horizontal canvas. So, we

[26:39] can now stream to Twitch, [music] Kick,

[26:41] YouTube, Facebook in horizontal, and

[26:44] then we got the vertical canvas for

[26:46] YouTube Shorts. Now, in order for us to

[26:48] live stream to TikTok from OBS Studio

[26:51] utilizing Aitum Multistream, there is a

[26:53] few things that we're going to have to

[26:55] do because Aitum at the moment does not

[26:58] have the rights to get stream keys from

[27:00] TikTok. They have not released that yet.

[27:02] And so, I do want to go ahead and inform

[27:04] you that this is going to be a

[27:06] workaround method. And in order for us

[27:08] to do this, we are going to have to go

[27:10] to this website, streamlabs.com,

[27:12] and you're going to have to download

[27:14] Streamlabs OBS. And once you've

[27:16] downloaded Streamlabs OBS, you are also

[27:19] going to have to come over to this

[27:20] GitHub page, which once again is going

[27:22] to be linked in the description of

[27:24] today's video, and you're going to have

[27:25] to download the Streamlabs TikTok stream

[27:28] key generator. Now, if you're on

[27:30] Windows, you want to download this, and

[27:32] if you're on a Mac with a M-series

[27:35] silicon chip, you want to download this,

[27:37] and if you are utilizing a Mac with a

[27:39] Intel processor, then you want to

[27:41] download this. Once you have Streamlabs

[27:44] OBS fully downloaded and open,

[27:47] you now need to go ahead and log in to

[27:50] your TikTok account.

[27:52] And there's two ways on how you're able

[27:53] to do that. The first way is by logging

[27:57] in

[27:58] by clicking on the login button on the

[28:00] lower left-hand corner, and you're going

[28:02] to see this page.

[28:04] You are then going to select the option

[28:06] that says login to TikTok, and once

[28:08] you're officially logged in, you will

[28:09] see your TikTok username on the lower

[28:11] left-hand corner. Now, another thing

[28:14] that you can do if you're already logged

[28:15] in to a different account, you can come

[28:18] over to where it says settings,

[28:20] you can go over to where it says stream,

[28:23] and it will provide you with all of the

[28:25] accounts that you're able to log into.

[28:27] Go ahead and select TikTok,

[28:29] and once you're signed into your

[28:31] account, you might run into a situation

[28:33] to where Streamlabs is asking for you to

[28:35] apply to go live on TikTok. And if

[28:38] that's the case, go ahead and click on

[28:40] the link to apply, and you will be met

[28:43] with this particular screen right here.

[28:45] And so, what you're going to do is once

[28:47] again, click on this button to apply,

[28:49] and you're then going to go ahead and go

[28:51] through this application. Now, some of

[28:53] you might not have to go through the

[28:54] application process. The moment that you

[28:57] log into your TikTok account, if it

[28:59] automatically connected and linked

[29:01] inside of Streamlabs OBS, then you're

[29:03] good to go. There's nothing else you

[29:04] need to do. You can go on to the next

[29:06] step. However, if you do have to apply,

[29:09] then go ahead and go through that

[29:10] process. You can get approved instantly,

[29:13] or it can take up to roughly around 72

[29:16] hours, and they will let you know if you

[29:18] got approved to go live or not. Now, in

[29:20] the off chance that you don't get

[29:21] approved, just go ahead and apply again

[29:23] until you get approved, so that way you

[29:26] can go ahead and move on to the next

[29:27] step. So, once you receive the approval

[29:30] from Streamlabs OBS, you now need to go

[29:32] ahead and open up the Streamlabs TikTok

[29:35] stream key generator that you have

[29:37] downloaded. Once you open up the

[29:39] application, you'll be met with this

[29:41] particular screen right here,

[29:43] and what you're going to want to do is

[29:45] select the option that says load from

[29:47] PC. You will then have your username pop

[29:50] up in this box, along with the status

[29:53] that says approved, and then it also

[29:55] will say that you can go live true. If

[29:58] this says false, then the only thing

[30:01] you're going to do is click on this

[30:02] refresh account information button. It's

[30:04] going to refresh this, and then you

[30:07] should then see where it says true. This

[30:10] will not work if you did not first get

[30:12] approved going through Streamlabs OBS.

[30:14] And so, once that's done, you're now

[30:16] going to go over to where it says stream

[30:19] control.

[30:20] You're going to select the option that

[30:22] says go live. It's going to say your

[30:24] stream has started successfully, and

[30:26] you're going to select okay.

[30:28] Now, really quickly, the stream key that

[30:30] you're getting from this generator tool

[30:32] is designed to work only one time. So,

[30:36] each and every single time that you want

[30:38] to go live on TikTok, you are going to

[30:40] have to open up the generator tool, so

[30:42] not Streamlabs, but just the generator

[30:45] tool itself. And you're going to have to

[30:47] generate a brand new stream key each and

[30:50] every single time that you want to go

[30:51] live on TikTok. Now, you also have the

[30:54] option to, of course, put your stream

[30:56] title and then your game category right

[30:58] here. And of course, if you have any

[31:00] mature content, you can also check that

[31:03] option right here.

[31:04] And so, what you're going to do now is

[31:06] you're going to copy the URL for the

[31:07] stream key, and you are then going to go

[31:10] back into OBS Studio.

[31:12] You are going to click on the gear icon

[31:14] for the Aitum Multistream.

[31:16] You are going to go to the vertical

[31:18] canvas.

[31:20] You're going to select the option that

[31:22] says add output.

[31:24] You're going to select TikTok.

[31:26] And you're going to paste the stream key

[31:28] that you received from the generator

[31:30] tool right here.

[31:31] And you are now going to go back to the

[31:33] generator tool.

[31:35] And you're going to copy the stream URL.

[31:38] And you're going to paste that in the

[31:40] TikTok server box right here.

[31:43] You are then going to create the output.

[31:46] And you now have TikTok added into Aitum

[31:49] Multistream for you to go live through

[31:52] OBS. So, you can now go ahead and select

[31:55] okay, and that's it. So, now we need to

[31:58] go ahead and set up our vertical canvas.

[32:00] So, what we're going to do is go over to

[32:02] our scenes and our sources.

[32:04] We're going to switch them to vertical

[32:07] scene and vertical sources. And you then

[32:10] going to go over to your vertical

[32:11] sources. You're going to click on the

[32:12] plus icon. If you want to add your

[32:15] webcam, once again, you're going to do

[32:16] video capture, and you will see that

[32:18] your webcam is listed right here.

[32:22] We're just going to go ahead and scale

[32:23] this down to size. So, I'm just going to

[32:25] bring this over a bit.

[32:27] See if we can locate that middle part.

[32:32] And then, what I like to do

[32:34] is just have it fit just like that.

[32:37] And then, we're going to the same thing

[32:38] with our gameplay. You're are to choose

[32:40] whichever one you chose. So, if you

[32:42] chose game capture, if you chose display

[32:44] capture, or window capture, select that

[32:46] one that you chose. I do display

[32:49] capture, so I'm going to leave mine at

[32:50] display. I'm going to go ahead and drag

[32:52] this right up under

[32:54] the webcam.

[32:56] And so, there we go. So, now you have

[32:57] your vertical canvas set up. You now can

[32:59] stream in vertical.

[33:02] You have everything that you need right

[33:03] now. So, what we're going to do is set

[33:05] up our audio.

[33:06] And so, what I'm going to have you do is

[33:08] go back to your regular scenes, as well

[33:10] as your regular sources.

[33:13] And if you're on Windows PC, I need you

[33:15] to go down to the description of this

[33:17] video. I need you to click on the link

[33:19] for the Win Capture Audio Beta

[33:21] application. I need you to download

[33:24] that.

[33:25] It should bring you directly to this

[33:26] screen right here. You want to make sure

[33:28] that you select the latest version. It's

[33:31] going to bring you to this page, and

[33:33] then you can download the very first

[33:35] one, which is the executable.

[33:37] Once you download this, and you install

[33:39] it, you are going to have to reset your

[33:42] OBS. Once you reset your OBS, I need

[33:45] both Windows and macOS users

[33:48] to now come over to your scenes. I need

[33:51] you to click on the plus icon,

[33:54] and I need you to create a brand new

[33:55] scene named audio.

[33:58] I want you to select okay. I want you to

[34:00] go ahead and select this down arrow to

[34:03] bring the audio all the way down to the

[34:04] bottom. And what I would like for you to

[34:06] do is open up your music player. So,

[34:08] that can be either Spotify or Apple

[34:10] Music. And I would also like for you to

[34:13] join a VC on Discord, if you're someone

[34:15] that's going to be utilizing Discord.

[34:18] And once that's done, I would like for

[34:20] you to come to your sources,

[34:22] click on the plus icon.

[34:24] I would like for you to then select the

[34:25] application audio capture beta.

[34:28] You are then going to name this music.

[34:31] Select okay.

[34:33] And then for your window, click on the

[34:34] drop-down menu and you want to look for

[34:37] Spotify Premium.

[34:39] Once you find it, go ahead and press it.

[34:42] And then press okay.

[34:45] Now, go over to your music player.

[34:48] And then just press play.

[34:51] You should now see inside of OBS Studio

[34:54] that the music is moving on its own.

[34:57] That's how you know that it is working.

[34:59] And so from here, we're going to do the

[35:00] same thing for Discord. So we're going

[35:02] to click on the plus icon once more.

[35:05] Application audio capture beta.

[35:07] Name this Discord.

[35:10] Select okay.

[35:12] And then we're just going to look for

[35:13] the Discord server that we are currently

[35:14] in right now.

[35:16] Mine is right here.

[35:18] Press okay.

[35:21] And now you have Discord.

[35:22] So anytime you join any VC, it's

[35:25] automatically going to update it and

[35:28] you'll be able to hear your friends

[35:29] talking inside of your stream.

[35:32] Now to add in your gameplay, what you're

[35:35] going to do is click on the plus icon.

[35:38] This time we're going to go to

[35:39] application audio output capture. This

[35:42] is what we've downloaded from that

[35:44] application and you are then going to

[35:46] name this gameplay

[35:48] audio.

[35:50] And then press okay. Now for this, what

[35:52] I'm going to have you do is come right

[35:55] here to this blue button that says add

[35:57] executables.

[35:58] And I just want you to spam it. Like

[36:00] just press all of it until you are no

[36:03] longer able to press it.

[36:05] Once it's grayed out, I need you to find

[36:07] the game that you currently have up. So

[36:10] for me, that's going to be Marvel

[36:11] Rivals.

[36:13] And then I'm going to take it out of

[36:15] here.

[36:17] And I'm going to have you check this box

[36:19] that says capture all audio except

[36:21] sessions from the selected executable.

[36:24] What this means is that everything

[36:27] within this box, so everything in here

[36:29] will not be heard on your stream. The

[36:32] only thing that's going to be heard is

[36:34] this one particular window that you're

[36:36] going to have open. So, for this right

[36:39] here is going to be Marvel Rivals.

[36:41] So, you are then going to go ahead and

[36:43] select okay.

[36:45] If you look at your gameplay audio,

[36:47] you should see it moving.

[36:49] Now, of course, you also do want to add

[36:51] in your microphone. So, for this, what

[36:53] I'm going to have you do is actually

[36:55] come over to your settings.

[36:58] I'm going to have you go over to audio.

[37:00] I want you to make sure that your

[37:02] desktop audio is turned off. You want to

[37:05] make sure you have this turned off

[37:06] because you will not have any control

[37:09] over your audio if you have this turned

[37:11] on. All of your audio will end up being

[37:13] in one particular place, and you do not

[37:15] want that. So, disable that.

[37:18] And then for your mic, you want to then

[37:20] go ahead and select your microphone. So,

[37:22] mine is going to be the Beacn mic.

[37:25] I'm going to select apply and okay.

[37:28] And now you will see that my microphone

[37:30] is right here.

[37:31] Discord is right here.

[37:33] Gameplay audio is right here. Music is

[37:35] right here.

[37:36] And so now what I'm going to do is add

[37:37] in our browser audio in case we're going

[37:39] to be watching something like YouTube on

[37:41] stream, we want to be able to separate

[37:43] that audio from everything else. So, I'm

[37:45] going to click on this plus icon,

[37:47] application audio capture beta.

[37:50] I'm going to rename this browser.

[37:52] Select okay.

[37:54] And then I'm going to look for YouTube.

[37:57] So, make sure you have it already open.

[38:00] I have it right here.

[38:02] I'm going to select okay.

[38:05] And now our browser should be right

[38:06] here. So, that's good to go.

[38:08] Now, for macOS users, this is what

[38:11] you're going to do. So, you're going to

[38:12] go over to your sources.

[38:15] You are going to click on the plus icon.

[38:17] And then you're going to see an option

[38:19] that says macOS audio capture.

[38:22] You're going to select that.

[38:24] You want to make sure that you already

[38:26] have everything up that you're going to

[38:28] be using while you're streaming. So,

[38:30] that's going to be Spotify, your game,

[38:33] that's going to be your browser if you

[38:36] want to like potentially watch YouTube

[38:38] at some point while you're live

[38:40] streaming or anything like that. So,

[38:42] here we're going to go ahead and name

[38:43] this music.

[38:45] Click okay.

[38:48] We're going to change the method from

[38:49] desktop audio to application audio

[38:51] capture.

[38:53] We are then going to select the

[38:54] drop-down menu under application.

[38:57] And right here, you will see it says

[38:59] Spotify.

[39:00] You will go ahead and click on it

[39:02] and select okay.

[39:04] Now, if you have music already playing,

[39:07] you're going to see it moving right

[39:09] here.

[39:10] And so, now we need to go ahead and add

[39:11] in the rest of our audio. So, I'm going

[39:13] to go ahead and click on the plus icon.

[39:15] Go back to Mac OS Audio Capture.

[39:18] We're going to name this one Discord.

[39:21] Select okay.

[39:24] Once again, application audio capture.

[39:27] And you will now see an option for

[39:29] Discord. So, we're going to go ahead and

[39:30] select that and then press okay.

[39:34] And so, now we have our music and

[39:36] Discord.

[39:37] And so, now we need to do the same thing

[39:39] for our browser source as well as our

[39:40] alerts.

[39:43] Now, the process for setting up our

[39:44] alert sounds is going to be a little

[39:46] different. So, what you're going to want

[39:48] to do is you want to head back over into

[39:50] Lumia Stream.

[39:52] You are then going to go back to the

[39:54] core category.

[39:55] You're going to select overlays.

[39:58] We are going to create a brand new

[40:00] overlay.

[40:02] We're going to name this alerts.

[40:06] Select add new overlay.

[40:11] And then what we're going to do is we're

[40:12] going to add a layer.

[40:14] Select the option that says alerts.

[40:18] Click alert.

[40:19] We are now going to go on the right-hand

[40:21] side and select the option that says

[40:22] manage alert.

[40:25] And then on the left-hand side, we have

[40:26] to select the option that says add

[40:28] alert. And so what we're going to do,

[40:31] I recommend typing the word follower.

[40:34] And then we're going to select the

[40:35] option for our Kick follower. If you

[40:37] want to do TikTok, you can do that. Um

[40:40] but you also going to select Twitch

[40:42] follower.

[40:43] And then once you select those,

[40:45] search for subscriber.

[40:50] And then you can do gifted subscription,

[40:53] Twitch gifted subscription, as well as

[40:55] Twitch subscriber.

[40:58] If you want to do YouTube, you have that

[41:00] option. That's up to you.

[41:02] And then once

[41:04] that's done, we're going to look for

[41:05] bits,

[41:08] which is Twitch bits. And then once you

[41:11] have all the other alerts that you want

[41:13] to add, so you can sift through all of

[41:15] these and you can look for which ones

[41:16] you want to add in here.

[41:18] You're going to select the option that

[41:20] says add alerts.

[41:22] On the left-hand side, you will see all

[41:24] of your alerts listed right here for

[41:26] you.

[41:27] And then what we're going to do is go

[41:28] through each one of these and we're

[41:30] going to add in our alert. And so in

[41:32] order to do that, we're going to go on

[41:33] the right-hand side. We're going to

[41:35] select the option that says image/video.

[41:38] And of course, if you have a static

[41:40] image, you're going to choose image. If

[41:42] you have a video, you're going to choose

[41:44] option that says change video. And so

[41:46] what I'm going to do here is I'm going

[41:47] to go ahead and select change video. And

[41:49] this is going to be the screen that

[41:51] showcases the alerts that you've

[41:52] imported. As you can see, I already

[41:54] imported some, but what you're going to

[41:56] do is you're going to come on the lower

[41:58] right-hand corner. You're going to

[41:59] select the option that says upload

[42:01] files. And your overlay packs should

[42:03] have alerts already built for those in a

[42:07] separate file. If you do not have them,

[42:10] or if they did not provide that to you,

[42:12] then I recommend going over to this

[42:14] website, etsy.com, and you can actually

[42:17] buy some alerts. They have really good,

[42:20] decent, animated alerts that's very

[42:23] clean, and it can fit almost any

[42:25] aesthetic, and you can get them fairly

[42:27] cheap if you have the money to buy them.

[42:30] However, if you don't, then I will leave

[42:32] a link to a few websites in which you

[42:34] can get animated alerts

[42:37] 100% for free. And now, once you

[42:39] selected your overlays,

[42:41] you're going to go ahead and select

[42:42] open, and you're going to import all of

[42:45] your files, and it's going to look just

[42:46] like this. And so, now for the fact that

[42:48] I'm adding in a follower alert, I'm

[42:50] going to go ahead and select follower.

[42:54] And then I can come down here to layout,

[42:56] and then I'm going to come down here to

[42:57] where it says push text, and I'm able to

[42:59] now adjust my text to fit inside of my

[43:04] alerts here.

[43:05] So, now I'm going to go ahead I'm going

[43:07] to do this for each and every single

[43:09] alert that's on the left-hand side of my

[43:11] screen.

[43:12] And so, now that I have these done, what

[43:14] I recommend doing now is color coding

[43:18] our alerts, so that way we know exactly

[43:21] which platform that the alerts are

[43:23] coming from. So, for example, the names,

[43:26] as well as like the tiers, we can change

[43:28] these, for example, green for Kick,

[43:32] so that way we know that this is coming

[43:34] from Kick.

[43:36] I'm going to do that for each and every

[43:37] single one of them here.

[43:41] And then, for Twitch,

[43:43] we're obviously going to go ahead and

[43:44] we're going to change this to purple.

[43:47] Perfect. And so, now what we're going to

[43:49] do is add in our alert audio. And so,

[43:52] what we're going to do is come on the

[43:53] right-hand side, we're going to select

[43:55] this option right here that says audio,

[43:58] and then we're going to click change

[43:59] audio.

[44:00] Now, if you want to know where you can

[44:02] go to get sound alerts for your live

[44:04] stream, I highly recommend checking out

[44:07] my instance.com.

[44:09] And this website has a boatload of

[44:11] effects that you can use for your alerts

[44:13] 100% for free. [music] So, let's say for

[44:16] example, we're just going to go ahead

[44:18] and do the Minecraft explosions. We're

[44:21] going to go ahead and we're going to

[44:21] click on it.

[44:23] And then there's going to be option that

[44:24] says download mp3.

[44:26] You can go ahead and download it. You're

[44:28] then going to go back into Lumia Stream.

[44:32] And you're going to select the option

[44:33] that says upload files. You're then

[44:35] going to go and locate wherever you

[44:38] downloaded the mp3 file. Press open, and

[44:41] now you have it sitting right here. So,

[44:43] we're going to go ahead and select it.

[44:45] We can then go ahead and change the

[44:46] volume. So, we'll put this down to like

[44:49] 20, maybe 30%. And you're then going to

[44:52] do this for each and every single alert

[44:54] that you have.

[44:56] Once that's done, you can go ahead and

[44:57] select save.

[45:00] And you're then going to go ahead and

[45:02] select the option that says copy URL.

[45:05] And we're now going to head back into

[45:06] OBS Studio.

[45:08] And so, now we're going to go to our

[45:09] sources. We're going to click the plus

[45:11] icon. We're going to select browser.

[45:14] We're going to name this alert.

[45:17] Select okay.

[45:19] We're going to paste the URL.

[45:21] And then we want to make sure that we

[45:23] check the option that says control audio

[45:25] via OBS.

[45:28] Go ahead and select it.

[45:30] You want to also go ahead and change the

[45:32] width and height. I personally just

[45:34] recommend doing 1920 by 1080.

[45:39] You're then going to go ahead and select

[45:40] okay.

[45:42] And now if you were to go ahead and open

[45:44] up Lumia Stream.

[45:46] And if you were to select the option

[45:48] that says emulate

[45:50] alert.

[45:51] And let's say we do follow.

[45:54] Twitch follow.

[45:56] Emulate.

[45:58] Look at that. It's now right here on

[46:00] stream.

[46:02] Now, of course, we want to do the one

[46:03] that has the actual sound to it. That's

[46:06] going to be our bits, so I'm going to go

[46:07] ahead and do that now.

[46:09] And you see it now inside of OBS that it

[46:12] is

[46:13] coming through on its own.

[46:15] So, we're now done with this. So, what

[46:17] we can do is click where it says alert,

[46:21] hold the shift key,

[46:22] and then select music at the bottom.

[46:26] We're going to right click, and then

[46:27] we're just going to go ahead and we're

[46:28] going to group the selected items.

[46:30] We're going to name this nested audio.

[46:35] Click inside the canvas,

[46:38] and this is now inside of a group. So,

[46:40] we can come back into, let's say, our

[46:42] gameplay

[46:43] scene.

[46:45] We can then go to our sources. We can

[46:46] click on the plus icon,

[46:48] select group,

[46:50] and then you'll see where it says nested

[46:52] audio. So, we can go ahead and click

[46:53] this

[46:54] and bring this in,

[46:56] and you now have all of your audio that

[46:58] you need inside of your gameplay scene.

[47:01] And then you can put your audio in any

[47:03] scene that you want to. Once that's

[47:05] done, we now need to go ahead and create

[47:08] our multi chat widget, so that way we

[47:11] can see all of our chats right here

[47:13] inside of OBS Studio. Now, luckily, you

[47:16] can also use Lumia Stream to also get a

[47:19] multi chat widget. So, what we're going

[47:21] to do is go ahead and open it right back

[47:23] up. And now, in order for you to get the

[47:25] widget, what you're going to want to do

[47:27] is you're going to want to go over to

[47:29] streaming tools,

[47:31] and then you're going to select the

[47:32] option that says Lumia link. On the

[47:34] right hand side, it's going to provide

[47:36] you with the option for the doc chat.

[47:39] You're going to go ahead and copy the

[47:40] link,

[47:42] minimize Lumia Stream.

[47:44] You're then going to go to your docs

[47:45] inside of OBS Studio.

[47:48] You're going to create a custom browser

[47:50] dock.

[47:52] And as you can see, I already have it

[47:53] right here, but I'm I'm to go ahead and

[47:55] I'm just going to

[47:56] paste the link that I received. I'm

[47:58] going to click apply.

[48:01] And it should automatically pop up for

[48:03] you.

[48:04] So, it should look

[48:08] like this.

[48:10] So, you can go ahead and you can just

[48:11] dock it right here.

[48:14] And the cool thing about this is that

[48:15] you can change the background to have

[48:19] any theme that you want. So, if there's

[48:21] like any kind of wallpaper that you want

[48:23] to have to put in the background, you

[48:25] are more than welcome to do that. So,

[48:27] basically what you're going to do, if

[48:29] you want to change that, is by going to

[48:31] the gear icon.

[48:33] And then it's going to provide you with

[48:34] some options. If you scroll down a

[48:36] little bit,

[48:37] it's going to bring you to the

[48:39] background image URL. So, let's say we

[48:42] go over to Google.

[48:44] And then let's say we type in 4K

[48:48] wallpapers.

[48:50] And then we look at an image.

[48:52] And let's say you want this wallpaper

[48:56] right here.

[48:57] If you right click on it and you copy

[48:59] the image address,

[49:01] and then if you paste it inside of Lumia

[49:03] Stream right here, click on the gear

[49:05] icon, you will see the background had

[49:08] changed.

[49:10] And then if you want to, you can go back

[49:12] into the gear icon

[49:14] and you can change the blur intensity.

[49:16] So, if we put this at zero, you would be

[49:18] able to see the full picture.

[49:21] And then if we were to bring it to 25,

[49:24] which I think that's a sweet spot,

[49:27] you now have a nice blurred image.

[49:30] So, you can have this set to any type of

[49:32] theme that you want, and I think that's

[49:34] pretty cool.

[49:36] So, now what we want to do is configure

[49:37] our quality settings, so that way we can

[49:39] have a good-looking stream and

[49:41] recording. So, what you're going to want

[49:43] to do is go over to your settings inside

[49:45] of OBS.

[49:47] You want to go over to the output tab.

[49:49] And And want to make sure that your

[49:50] output mode is set to advanced. It's

[49:53] going to provide you with other options

[49:55] down here that we're going to change.

[49:57] You want to make sure that you're under

[49:58] the streaming tab.

[49:59] And then for your audio track, you want

[50:01] to make sure you have that set to one.

[50:03] You want your audio encoder set to

[50:05] FFmpeg AAC.

[50:08] You want to check this box to enable the

[50:10] Twitch VOD track. This is going to allow

[50:13] you to put your audio into a separate

[50:15] track, so that way you can control

[50:17] exactly what goes into your VODs.

[50:20] And then for your video encoder, you

[50:22] want to make sure this is set to your

[50:23] graphics card. So, you'll either have an

[50:26] Nvidia graphics card or an AMD graphics

[50:29] card. Make sure you select it, and make

[50:32] sure it is a H.264.

[50:35] And then if you're on Mac, well, it's

[50:37] going to say Apple VT H.264 hardware

[50:41] encoder. You want to make sure that you

[50:43] select that.

[50:46] Once that's done,

[50:48] go to rescale output.

[50:50] Make sure that's disabled.

[50:52] And then for your encoder settings, your

[50:54] rate control, you want to make sure you

[50:55] have that at constant bitrate or CBR.

[50:58] They mean the same exact thing.

[51:01] For your bitrate, I'm just going to

[51:02] flat-out tell you to put 8,000.

[51:05] If you notice in your stream that you

[51:08] are lagging, then you're going to take

[51:10] that bitrate and you're going to

[51:11] subtract 500 until you are no longer

[51:15] lagging, but do not go under 6,000. As

[51:18] 6,000 is what's needed for you to have a

[51:21] 1080p 60 FPS stream.

[51:24] Now for your keyframe intervals, you

[51:26] want to have this at 2 seconds. Your

[51:28] preset, you want it at P5 slow good

[51:31] quality. Your tuning, you want it at

[51:34] high quality.

[51:35] Your multipass mode, you want it at two

[51:37] passes quarter resolution.

[51:40] Your profile, you want it set to high.

[51:42] Your look ahead and your depth of

[51:44] quantization, have both of those

[51:46] checked. And then your B frames, have

[51:48] that set to two.

[51:50] This should be a really good setup for

[51:53] any PC to allow you to stream in 1080p

[51:57] 60 FPS at a really good quality.

[52:02] Now, if you are still lagging after you

[52:04] bring your bit rate down to 6,000, then

[52:06] what I recommend doing is changing your

[52:09] tuning from high quality and you can

[52:11] change that to ultra low latency.

[52:14] Now, once that's done you can go over to

[52:16] your recording tab.

[52:18] And then what we're going to do is

[52:19] you're going to leave your type to

[52:21] standard.

[52:22] Your recording path, you're going to put

[52:24] this wherever you want your videos to

[52:25] go.

[52:27] For your recording format, I highly

[52:29] recommend choosing hybrid MP4. This is

[52:32] going to allow for your OBS to save your

[52:35] videos in case something were to go

[52:37] wrong. For example, if your power goes

[52:39] out, your PC stops, if you run out of

[52:43] storage space, it's automatically going

[52:45] to save it from where it stopped. So,

[52:47] make sure you use hybrid MP4.

[52:51] Now, for your video encoder you want to

[52:53] make sure you're selecting your

[52:54] dedicated graphics card.

[52:56] So, that's going to be same thing as

[52:57] before.

[52:59] Either Nvidia or AMD H.264

[53:02] or Apple VT

[53:04] H.264 hardware encoder.

[53:07] Once again, you want your audio at

[53:09] FFmpeg AAC.

[53:12] And then for your audio track you want

[53:14] to uncheck one or two because that's

[53:17] going to be your stream chat as well as

[53:19] your VOD track from Twitch.

[53:22] And then you want to select three, four,

[53:24] five, and six.

[53:26] This is going to allow for you to have

[53:28] separate audio tracks for when you are

[53:30] taking your recordings and putting that

[53:33] into your editing software such as

[53:35] DaVinci Resolve or Adobe Premiere Pro or

[53:38] even CapCut. Now, for your rescale

[53:39] output, you also want to make sure

[53:41] that's disabled.

[53:42] You're going to scroll down once again

[53:44] to your encoder settings. Now, for your

[53:46] rate control, I recommend you use

[53:48] constant QP if you're on Windows. And

[53:51] then for your constant QP settings, you

[53:53] want to set this anywhere between 15 to

[53:56] 22.

[53:57] Now, just know that the lower that you

[53:59] set this number, the bigger your file

[54:02] size is going to be, but the better

[54:04] quality that you are going to achieve.

[54:06] 15 is going to be a really, really good

[54:09] sweet spot for you. So, I use 15, and I

[54:12] highly recommend you do the same. But,

[54:14] if you don't have enough space on your

[54:16] computer, then go ahead and increase the

[54:18] number. Just don't go any higher than

[54:19] 22, otherwise your quality is going to

[54:21] look really bad.

[54:24] Now, for your keyframe intervals,

[54:26] once again, you want to do 2 seconds,

[54:28] preset P5, tuning high quality,

[54:32] multi-pass mode two passes quarter

[54:34] resolution, profile set that to high,

[54:37] look ahead and your adaptive

[54:39] quantization, set that to two.

[54:42] Now, if you're on Mac, what you're going

[54:44] to want to do is the CBR, since they

[54:47] don't have the option for uh constant

[54:50] QP, you're going to do CBR, and then you

[54:52] can also leave your uh bit rate to

[54:56] 8,000. Once that's done, you can now go

[54:58] ahead and select apply and okay. And

[55:01] then you're going to come over to your

[55:03] Atom multistream dock.

[55:05] You're going to go into the gears icon.

[55:09] And then for your main canvas,

[55:12] you're going to go over to advanced

[55:13] settings.

[55:15] Now, there's two ways on how you're able

[55:17] to do this here. You can leave this as

[55:20] your main encoder, and what this means

[55:22] is that it's going to piggyback off the

[55:25] quality that you have from Twitch. So,

[55:28] you go live on Twitch first, and then if

[55:31] you decide to go live on YouTube, Kick,

[55:33] or Facebook, you can do that, and then

[55:35] it's just going to piggyback off the

[55:36] same quality that you have for Twitch.

[55:40] However, if you want to let's say one

[55:42] day just stream to YouTube and YouTube

[55:45] only, or if you want to have a specific

[55:49] quality for YouTube and a different

[55:52] quality for

[55:53] Twitch, then what you can do is change

[55:56] your video encoder

[55:58] to your graphics card.

[56:01] So, you're going to scroll down from

[56:03] here.

[56:04] And then you're going to change your

[56:06] rate control to constant bitrate. For

[56:09] YouTube, we're going to set it to

[56:10] 12,000.

[56:12] Your key frame interval should be the

[56:14] same for Twitch. And everything else

[56:17] down below should be exactly as you see

[56:19] it on my screen.

[56:22] And then you're going to do the same

[56:23] thing for Kick and Facebook.

[56:26] For So, for Kick, if you want to do your

[56:28] graphics card, what you can do, and then

[56:30] you're going to scroll down and you're

[56:31] going to change this to 8,000. Key frame

[56:35] interval is going to be 2 seconds. And

[56:37] then everything else should be as you

[56:38] see on my screen. And then you're going

[56:40] to do the same thing for Facebook. It's

[56:42] going to be the same exact settings as

[56:44] Kick.

[56:46] So, scroll down, 8,000.

[56:49] Set this to two.

[56:51] And then everything else should be

[56:52] exactly as you see it on my screen.

[56:54] Now, once that's done, you can head on

[56:56] over to the vertical canvas. And then

[56:58] you're going to go over to the advanced

[57:00] settings for TikTok.

[57:02] And then what you can do is you can set

[57:05] this to your graphics card.

[57:07] And then you're going to set this to

[57:09] 6,000.

[57:11] Everything else is going to be the same

[57:12] as our previous settings.

[57:15] And you'll be able to copy it from my

[57:16] screen here.

[57:18] And if you want to try to get better

[57:20] quality, which you don't really have to

[57:22] do, but if you want to, you can bring

[57:24] this bit rate up to 8,000 and then

[57:28] you should be just fine.

[57:30] So now

[57:33] make sure that the YouTube Shorts is the

[57:35] same as the horizontal

[57:38] 12,000

[57:41] 2 seconds.

[57:44] Make sure you copy exactly what you see

[57:46] on screen.

[57:48] And you can now go ahead and press okay.

[57:52] And so, you now have successfully set up

[57:54] OBS Studio for live streaming and

[57:57] recording.

[57:58] Now, there's two more things that you

[58:00] just need to do and then you are 100%

[58:03] completely done.

[58:05] The first thing you need to do is come

[58:07] over to the vertical canvas.

[58:09] You're going to click on the gears icon.

[58:12] And we're going to set up our back track

[58:14] so that way you can set up a hot key to

[58:17] clip your content so that way you can

[58:19] just quickly edit and upload it to

[58:21] YouTube Shorts or to TikTok.

[58:24] You want to make sure your resolution is

[58:25] at the 1080 by 1920.

[58:28] You can leave everything else as is up

[58:30] here.

[58:31] Come down to your back track.

[58:33] Make sure that this is checked. So, that

[58:36] way whenever you start streaming or

[58:37] whenever you start recording, you will

[58:39] automatically start your back track.

[58:43] And then for your recording length,

[58:45] you're going to set this to either 90

[58:46] seconds or to 120

[58:49] seconds. That's literally up to 2

[58:51] minutes of footage that you have to work

[58:53] with. So, the moment that something

[58:55] happens that you want to clip, you can

[58:57] go ahead and press the hot key on your

[58:59] keyboard or on your stream deck and it

[59:01] will automatically record those last 2

[59:03] minutes or minute and 30 seconds of

[59:04] gameplay. So, you can come right here

[59:07] where it says save back track hot key

[59:09] and you can set that hot key. Once

[59:11] that's done, you can select okay and

[59:14] you're good to go.

[59:15] Now, lastly, we're going to come to our

[59:17] audio mixer here.

[59:19] We're going to select this little gear

[59:21] icon.

[59:23] And then it's going to bring up your

[59:25] advanced audio properties.

[59:27] What you're going to want to do

[59:29] is you want to uncheck

[59:32] everything in three,

[59:34] four,

[59:35] five,

[59:36] and six

[59:38] inside of track two.

[59:41] You want to uncheck the music, so that

[59:43] way your music is not being heard in

[59:45] your Twitch VOD track, so that way it

[59:48] can just automatically get uploaded to

[59:49] Twitch without having any issues.

[59:54] You are also going to uncheck the

[59:57] alerts, and this is personal preference.

[59:59] I just recommend doing that. Now, for

[1:00:01] three, four, five, and six, what you're

[1:00:04] going to want to do is have your

[1:00:05] microphone on track three.

[1:00:08] You are going to have your gameplay

[1:00:10] audio on track four.

[1:00:12] You're going to have your

[1:00:14] Discord audio on track five.

[1:00:17] And then you're going to have your music

[1:00:19] on track six.

[1:00:21] Your browser on track six.

[1:00:24] And if you want to, you can have your

[1:00:26] alert as well on track six. That's

[1:00:29] personal preference.

[1:00:30] >> [music]

[1:00:30] >> You decide on what you want to do.

[1:00:32] Once that's done, you're going to go

[1:00:34] ahead and select close. And when you

[1:00:36] record your content and you upload it

[1:00:38] into

[1:00:40] your editing software such as DaVinci

[1:00:41] Resolve or Adobe Premiere Pro, it should

[1:00:44] look exactly like this.

[1:00:48] Now, I know that that was a lot, but you

[1:00:50] have finally made it to the very end of

[1:00:52] this video. And so, I am proud of you

[1:00:55] for making it this far. You can now go

[1:00:57] ahead and enjoy the fruit of your hard

[1:00:59] work and dedication. And so, with that

[1:01:01] being said, that's going to be all for

[1:01:02] today's video. And so, if you made it to

[1:01:04] the end of you found this helpful, make

[1:01:06] sure you give this a big fat thumbs up.

[1:01:08] Make sure you guys go ahead and smash

[1:01:09] that subscribe button. And if you guys

[1:01:11] want to watch more tutorials similar to

[1:01:13] this, make sure you click on this video

[1:01:15] right here, as YouTube did pick this

[1:01:17] video specifically for you. And I'll

[1:01:19] catch you guys in the comments down

[1:01:21] below, as well as in the next video.
