hi this is light and I'm the riger of
[00:02]
the scores premade that we will be
[00:03]
releasing soon since this model supports
[00:06]
V Bridger we got a bunch of questions
[00:07]
all about V Bridger so I'm here to
[00:09]
explain as much as I can first of all
[00:11]
what is V Bridger V Bridger is a fast
[00:13]
tracking plugin for vtu Studio that
[00:15]
allows for more accurate face tracking
[00:17]
using the iPhone's AR kit tracking it is
[00:19]
created by the arton and exerp what do
[00:22]
you need for V Brier obviously you will
[00:24]
need a model with v Bridger riging V
[00:26]
Bridger ATT tracking device like iPhone
[00:29]
webcam or Android ATT tracking software
[00:31]
like ey facial Mo cap face motion 3D
[00:34]
meow face VP Studio Nida tracking or
[00:36]
media pipe when you first open a v
[00:39]
Bridger via steam you're going to see
[00:40]
this little window pop up which can look
[00:43]
very confusing at first if you don't
[00:44]
know what's going on but setup is
[00:45]
actually a lot easier than you might
[00:47]
think first you're going to go ahead and
[00:49]
select whatever tracking softare you're
[00:50]
using for tracking in this case I'm
[00:52]
going to use ey facial map with my
[00:54]
iPhone next you're going to look for
[00:56]
your iPhone IP address usually that can
[00:58]
be found in your Wi-Fi settings but in
[01:01]
the case of IAL moap it is popping up
[01:03]
right after you open I moap simply put
[01:07]
the IP address in this little window
[01:08]
right here and press connect to phone
[01:11]
once you have that connected you will
[01:12]
see that the head is now moving in order
[01:15]
to connect VB with vtube Studio you need
[01:17]
to make sure that you have plugins
[01:18]
turned on in vtube studio to check
[01:21]
simply go to the
[01:22]
settings and the first icon scroll down
[01:26]
until you see the vtube studio plugin
[01:28]
just make sure that it's turned on once
[01:30]
you have confirmed that it is turned on
[01:31]
in vtu studio go back to V Brier and
[01:34]
click on the little connect button on
[01:35]
the bottom right in vtu studio there
[01:38]
will now be a little popup window asking
[01:40]
for Access simply click
[01:42]
allow and boom now you connected with re
[01:45]
Bridger if you want to connect with your
[01:47]
webcam it's similar setup as the iPhone
[01:49]
setup simply choose the tracking serfer
[01:51]
you want to use first people will use
[01:53]
Nidia tracking click Start and then this
[01:56]
window on this little guy will pop up
[01:59]
please ignore how laggy it is for me I
[02:01]
have a really old webcam that does not
[02:03]
track properly
[02:05]
okay if you notice that you are looking
[02:07]
a little bit to the far right even
[02:09]
though you're looking straight ahead
[02:11]
click simply calibrate and then boom
[02:13]
easy done next up is Media pipe again
[02:18]
simply click on the media pipe click
[02:21]
Start and then there will also be
[02:23]
tracking again same thing if you're
[02:25]
looking to the side even though you're
[02:26]
looking at the front make sure to just
[02:28]
click calibrate
[02:30]
only downside to webcam tracking is that
[02:33]
um it does not
[02:34]
support a separate jaw tracking so you
[02:37]
cannot do stuff like um like the doie
[02:40]
bird jaw like the shocked face please
[02:43]
also ignore how funny the tracking looks
[02:46]
right now I'm normally using iPhone the
[02:48]
parameters I'm normally using do not
[02:50]
work with webcam so I would technically
[02:51]
need to go into V studio and adjust them
[02:54]
just like with any other model you will
[02:56]
need to make sure that the movement fits
[02:58]
your own movement the riger will already
[03:01]
have the model set up but according to
[03:03]
their movement so the way they move may
[03:06]
not be the way you move so for V Bridger
[03:08]
in this case we will look for those
[03:11]
parameters mouth smile mouth open jaw
[03:14]
open shr lip press funnel pucker cheek
[03:19]
puff I will go over what they do uh one
[03:22]
by one first is mouth smile mouth smile
[03:25]
is already in the name it tracks your
[03:28]
mouth form AKA either smiley face or sad
[03:31]
face mouth open is obviously the mouth
[03:34]
open like the ah ah ah jaw open is for
[03:39]
the jaw tracking also like
[03:42]
the the chewing shr is the like a little
[03:47]
like a little pouty
[03:48]
face where your mouth moves upwards lip
[03:52]
press is either like a Tey
[03:54]
smile or pressing your lips together
[03:59]
funnel is a little o like a little kissy
[04:02]
phrase
[04:03]
o pucker is again either shrinking your
[04:07]
mouth a little together for more kissy
[04:09]
or widening your mouth if you
[04:11]
smile cheek puff
[04:14]
is puffing your
[04:17]
cheeks first up mouth smile feel free to
[04:20]
copy all of my V settings to see if they
[04:22]
work for you in case they don't we will
[04:25]
now go over how to adjust them so if you
[04:27]
see this and you're wondering what's
[04:29]
going on don't worry I will explain so
[04:32]
first on the left side you have the
[04:33]
input which is the tracking input on the
[04:36]
right side you have the output which is
[04:37]
the which is the parameter in life 2D
[04:40]
the Red Dot over here is the tracking
[04:42]
input with a range that we will adjust
[04:44]
later on the right side you have the
[04:46]
output with the ma maximum and minimum
[04:48]
of the life Tod parameter and then we
[04:50]
have limit range limit range makes sure
[04:53]
that the little red dot does not exceed
[04:55]
our input this will cause the value to
[04:58]
stop smoothly When approaching the limit
[05:01]
then we have smoothing as the name says
[05:03]
it will smooth the movement but it will
[05:05]
also cause some sort of delay so for
[05:08]
example if I now put my smoothing on
[05:10]
100% on my mouth you can see the mouth
[05:13]
tracking suddenly becomes lot less
[05:15]
accurate and snappy so in case of mouth
[05:18]
I like to put it at either zero or one
[05:22]
uh one for me personally because I like
[05:24]
a little less Snappy M and I like a a
[05:26]
little bit of SM like a little bit of
[05:28]
like Smooth like transition
[05:31]
so for mouth smile you want to start
[05:33]
smiling and see what number you hit on
[05:34]
the very
[05:35]
left in my case it's Z it's 0.95 so I
[05:39]
put that in here please note that the
[05:41]
higher the number the more work you have
[05:44]
to put in with your face in order to
[05:47]
smile and the lower the less you have to
[05:50]
smile so for example if I were to put it
[05:53]
at let's say
[05:55]
0.7 I have to do a lot less work IRL to
[05:58]
start smiling
[06:01]
and just the slightest smile will
[06:03]
trigger to go up and start tracking the
[06:05]
full-on
[06:07]
smile same we will do for the frowning
[06:10]
or like the sad
[06:12]
[Music]
[06:15]
mouth let's say from
[06:19]
0
[06:25]
[Music]
[06:27]
09 that's why I like the it's a bit too
[06:30]
extreme for me
[06:33]
right I don't like how fast or like how
[06:36]
extreme that mouth goes into sad mouth
[06:39]
I'm just going to keep it at zero
[06:40]
because then I have to I would need to
[06:43]
put like a little bit more work in to
[06:44]
like start frowning but I like the way
[06:47]
it looks for me I just put it at zero
[06:50]
again play around with these numbers to
[06:52]
see what fits best for
[06:53]
you and then I limit my
[06:57]
range and then next two mouth open same
[06:59]
thing over here I'm going to unlimit
[07:01]
these for you first
[07:04]
so important thing to know that when you
[07:08]
um adjust mouth open you want to make
[07:10]
sure that you have the exact same
[07:12]
numbers in jaw open that is because jaw
[07:15]
open checks separately from the mouth
[07:18]
open meaning the mouth open is simply
[07:20]
just the movement of the O A going from
[07:24]
close to ah open the jaw is like the
[07:27]
inner mouth movement so or stuff
[07:31]
like the jaw moving up and down so if
[07:34]
the numbers don't match you can encou uh
[07:37]
encounter something called dislocated
[07:39]
jaw where it looks really funny and
[07:42]
really weird where your jaw is not
[07:45]
moving in line with your act mouth which
[07:48]
can look a little bit funny so make sure
[07:51]
that if you adjust these that they match
[07:55]
again same for open mouth the lower this
[07:57]
number is the less work you have to put
[07:59]
it into opening your actual mouth please
[08:02]
don't put it too low because that can
[08:05]
result into some very Snappy mouth
[08:07]
movement for example if I were to put at
[08:11]
two that goes like this and I don't want
[08:13]
this because I still want it to look
[08:15]
natural and not like I
[08:16]
am going
[08:20]
crazy so again just talk normally and
[08:23]
see what number you're usually hitting
[08:24]
when
[08:25]
talking the reason I put this to 0.08 is
[08:29]
for the mouth to uh close a little
[08:31]
earlier just so I don't have like little
[08:34]
cuz I tend to have my mouth open a
[08:36]
little bit while thinking working
[08:38]
whatever so this is like a little
[08:39]
threshold for me where the mouth opens a
[08:41]
little H closes a little faster than if
[08:44]
I put it on zero I can show you guys
[08:47]
what looks like on zero the mouth closes
[08:50]
a little bit um later now than what the
[08:53]
before and I don't want that personally
[08:56]
so I just put it a little bit higher to
[08:58]
like 0.08
[09:00]
so the mouth closes a little
[09:04]
earlier next up is shrug which is again
[09:07]
the moving your mouth up like a
[09:11]
pout simply again same thing over here
[09:15]
check what number you hit when you go
[09:17]
[Music]
[09:21]
pout
[09:23]
around7 we could actually adjust that if
[09:26]
you want some Snappy snappier truck I
[09:29]
can
[09:30]
go and
[09:34]
now I go I go
[09:36]
Snappy again I personally don't like
[09:39]
that I want a less Snappy and more like
[09:42]
I put more work to hit the
[09:45]
maximum as you can see over here the
[09:46]
output I hit the out the maximum output
[09:49]
a lot faster if I put it at seven at 7
[09:52]
than if I put it at
[09:55]
one again personal preference adjust how
[09:58]
to your liking
[10:00]
lip press lip press is again either the
[10:03]
smiley face which is the one up on top
[10:05]
the or the on the bottom go smiley face
[10:11]
and see what number you're
[10:13]
hitting and go and then press your lips
[10:17]
together to see what number you're
[10:18]
hitting and adjust to your adjust
[10:21]
accordingly again I put these at my
[10:23]
numbers you go you go you you do you
[10:27]
funnel is the little kissy mouth that I
[10:29]
like the O sounds
[10:31]
o
[10:34]
o again same concept here do like a
[10:38]
little old
[10:39]
face next up is Packer same thing Packer
[10:42]
again either widens the mouth and
[10:44]
smiling so if I were to put this at the
[10:47]
lower number
[10:49]
so
[10:51]
three my mouth would widen a lot
[10:55]
more this only mostly affects when the
[10:58]
mouth is closed instead of when the
[10:59]
mouth is open uh so yeah uh upper the
[11:03]
upper number is for like the widening of
[11:05]
the mouth while the lower number is for
[11:07]
like the posing together more
[11:11]
H and then cheek puff cheek puff as the
[11:14]
name says you cheek your you puff your
[11:18]
cheeks again check what number you're
[11:20]
hitting when you go cheek
[11:25]
puff and put it in there something also
[11:28]
read in the Twitter comments is that
[11:29]
someone adjusted all of the rudo
[11:31]
parameters but their mouth still barely
[11:33]
moved and there's actually a little
[11:35]
small thing for that that could help you
[11:38]
that you probably didn't know
[11:40]
about so in V Bridger you have this
[11:43]
little thing over here says Bridget
[11:45]
which is the name of her of the little
[11:47]
gorgeous lady over here and then
[11:48]
something called safe and load important
[11:52]
for us is the load in this case which
[11:54]
will open this little
[11:56]
folder and also kill our tracking from V
[11:59]
Bridger has a bunch of V Bridger presets
[12:02]
which affect these things over here so
[12:05]
the default will be Advanced AR kit
[12:07]
settings V Bridger which is also what
[12:08]
I'm using personally again personal
[12:10]
preference this is all personal
[12:12]
preference but there are a lot more with
[12:14]
the newest being a kit version
[12:17]
3.0 these all have different kind of
[12:20]
settings and sensitivities so just for
[12:22]
example go with the two
[12:25]
2.0 and you can see it's a lot different
[12:28]
and a lot like more reactive than the
[12:31]
before if it's too reactive just go back
[12:33]
to vtube Studio check the settings you
[12:36]
need to check all of the settings not
[12:38]
just the mouth as you can see the face
[12:39]
the entire body is a lot more reactive
[12:42]
now to just the smallest movement you
[12:44]
will need to go through all of your
[12:45]
vtube studio settings and check all the
[12:47]
parameters and adjust
[12:49]
accordingly if for some reason this is
[12:52]
still you're like I still don't like
[12:53]
this go back to this um for example try
[12:57]
the 3.0
[12:59]
and then see if it STS more to your
[13:01]
liking again go ahead and adjust
[13:03]
everything to your liking and see what
[13:05]
works best for you another important
[13:07]
thing to add us while setting up your
[13:09]
parameters is important puppeteering is
[13:12]
just as important you have probably seen
[13:14]
it all over Twitter people complaining
[13:16]
oh I got V Bridger I got this I got that
[13:19]
but it doesn't look good it doesn't look
[13:21]
the same as others and that is because
[13:23]
you're not moving your face right B
[13:25]
Bridger tracking is a lot more sensitive
[13:28]
and accurate to your IR tracking than
[13:31]
normal tracking as because you have a
[13:33]
lot more range of movement now right you
[13:35]
have like different facial movements you
[13:38]
can do different mouth shapes you can do
[13:40]
and those reflect your IRL movement a
[13:42]
lot more so it is important to open your
[13:45]
mouth exaggerate your mouth movement
[13:48]
Unleash Your Inner anime girl and go
[13:51]
ham I can only recommend pulling up your
[13:55]
V model like a lot and just look look at
[13:59]
it talk sing along every musical sing
[14:03]
along just move move your mouth you it
[14:06]
will be high at first I personally still
[14:09]
struggle with it a lot I'm still
[14:11]
practicing myself it will hurt your face
[14:15]
if you just start doing it but it is so
[14:17]
important for a really good looking and
[14:20]
great
[14:21]
looking great looking facial tracking
[14:25]
there are some things that can make
[14:26]
tracking a little harder one is
[14:28]
excessive facial hair if you have a full
[14:30]
beard tracking may not look as good for
[14:32]
you as it does with others since the
[14:34]
it's hard to track with a beard covering
[14:37]
up most of the mouth or just like being
[14:39]
in the way another thing I've heard a
[14:41]
lot are glasses I myself I wear a
[14:43]
glasses IRL I have not encountered any
[14:46]
issues so far with for example eye
[14:48]
tracking um but that's because I mostly
[14:51]
probably in a well L room I have the
[14:54]
kind the type of glasses uh where it
[14:56]
doesn't reflect the light part um
[14:59]
so I personally didn't have any issues
[15:02]
so far with that another thing that I've
[15:04]
seen a lot is the question where to
[15:06]
place your phone so the best placement
[15:09]
would technically be straight ahead of
[15:10]
you but most of the time that would't
[15:12]
work because you have your monitor in
[15:13]
front of you probably so the setup of
[15:17]
the phone is kind of depends on your own
[15:20]
um monitor setup I personally have it a
[15:22]
little like below my monitor facing
[15:25]
pretty much straight still um at me uh
[15:29]
um I've also seen people putting theirs
[15:31]
above their monitor face uh like tilted
[15:34]
down a little bit uh which I heard can
[15:37]
work better for people that have like
[15:40]
very pronounced Jaws um so it's
[15:43]
basically just a lot of like checking
[15:46]
replacing and seeing again what works
[15:48]
best for you another thing I saw is um
[15:52]
the question on how to keep your phone
[15:54]
in the same position and I can highly
[15:57]
highly highly highly recommend
[15:59]
those phone stands from Amazon I have
[16:02]
this one which look a little bunny which
[16:04]
I thought was cute even though you
[16:05]
cannot even see the bunny ears but any
[16:08]
phone stand will do to keep your phone
[16:10]
in place again I do recommend one that
[16:13]
uh can also like you can tilt your phone
[16:15]
maybe like up and down a little and just
[16:17]
adjust it a lot more now question is
[16:20]
what iPhone is best for tracking iPhone
[16:23]
first introduces the whole AI kit and
[16:25]
facial ID for the iPhones with the
[16:27]
iPhone 10 so yes you can get an iPhone
[16:29]
10 for tracking I don't recommend it
[16:32]
though because it it is the first phone
[16:34]
of theirs that has that tracking so it's
[16:37]
not as good as the newer ones no you
[16:39]
don't need to get the new iPhone 2500
[16:42]
million Pro Ultra for tracking anything
[16:46]
after anything after iPhone 10 like
[16:48]
iPhone 11 and upwards will work just
[16:51]
fine I myself I'm also using an iPhone
[16:53]
11 just for tracking you also don't need
[16:55]
to get a super new iPhone just for
[16:57]
tracking if you already have an iPhone
[17:00]
you can use that I got myself an iPhone
[17:02]
just for the purpose of tracking since I
[17:04]
already have a perfectly working phone
[17:06]
but it's an Android so I I cannot use
[17:09]
that for tracking I did not buy as
[17:12]
myself a new phone I got myself a used
[17:15]
phone um via refurbished I don't know if
[17:19]
if it's global Shipping I know it
[17:22]
shipped to Germany which they basically
[17:24]
they have old the used phones and then
[17:26]
they make them look new and resell them
[17:28]
whatever you can also just look on eBay
[17:31]
or wherever you can buy used electronics
[17:34]
and see what works best uh so you don't
[17:38]
need to go out and buy a brand new
[17:40]
iPhone for this it can be used if for
[17:44]
just if you just using it for tracking
[17:46]
it does not need to be brand new I also
[17:48]
saw the question if V Bridger works with
[17:50]
3D models and I've read that it does I
[17:53]
cannot really talk about it much because
[17:55]
I don't have a 3D model or one that
[17:57]
supports AI kit or V briger so I would
[18:01]
definitely go out and check on YouTube
[18:03]
on Reddit or uh anywhere in the internet
[18:07]
to see if PE like how to connect it
[18:09]
there how to make it work cuz I wish I
[18:11]
could show it to you guys but I don't
[18:12]
have a 3D model like that if you ran
[18:15]
into any problems for troubleshooting I
[18:18]
highly highly recommend joining the vber
[18:20]
Discord they have a whole section just
[18:23]
for traveles shhoting and they're super
[18:24]
helpful I've been there before as well
[18:27]
because some issues I can highly highly
[18:30]
highly recommend going there for
[18:31]
troubleshooting if you have any other
[18:33]
questions feel free to ask them I will
[18:36]
try to answer them if not again the do
[18:38]
Discord is always available they're
[18:40]
super helpful and I can only recommend
[18:42]
that if you guys made it to the end of
[18:43]
the video congratulations and thank you
[18:45]
so much for watching I hope this little
[18:48]
tutorial helped some of you and I wish
[18:50]
you guys an amazing day and happy moving
